- Riding Modes
- Power Modes
- Bosch Cornering ABS EVO
- Ducati Traction Control (DTC) EVO
- Ducati Wheelie Control (DWC) EVO
- Ducati Slide Control (DSC)
- Engine Brake -Control (EBC) EVO
- Auto tyre calibration
Electronic fuel injection system. Twin injectors per cylinder. Full ride-by-wire elliptical throttle bodies with aerodynamic valves. Variable length intake system
Cooling System
Liquid cooled
Maximum Power
221 HP @ 15250 RPM
Maximum Torque
112 NM @ 11500 RPM
Display
Last generation digital unit with 5" TFT colour display
Brakes
Front Brake
2 x 330 mm semi-floating discs, radially mounted Brembo Monobloc Stylema (M4.30) 4-piston callipers with Bosch Cornering ABS EVO
Rear Brake
245 mm disc, 2-piston calliper with Bosch Cornering ABS EVO
Chassis and Suspension
Frame
Aluminum alloy "Front Frame" with optimized stiffnesses
Front Suspension
Fully adjustable 43 mm Ohlins NPX pressurized fork with TiN treatment.
Rear Suspension
Fully adjustable Ohlins TTX36 unit. Aluminium single-sided swingarm. Adjustable pivot position +/- 3 mm
Tyres
Wheels / Rim
Front wheel : 3-spokes forged aluminum alloy 3.50" x 17"
Rear wheel : 3-spokes forged aluminum alloy 6.00" x 17"
Front Tyre
Pirelli Diablo Supercorsa SP 120/70 ZR17
Rear Tyre
Pirelli Diablo Supercorsa SP 200/60 ZR17
Dimensions
Seat Height
830 mm
Wheelbase
1471 mm
Weight
193kg
Kerb Weight
172 kg
Fuel Tank Capacity
16 litres
Additional Details
Exhaust : 4-2-1-2 system, with 2 catalytic converters and 2 lambda probes
Standard : Euro 4
Gearbox : 6 speed with Ducati Quick Shift (DQS) up/down EVO
Primary drive : Straight cut gears; Ratio 1.80:1
Ratio : 1= 38/14 2= 36/17 3 = 33/19 4=32/21 5=30/22 6=30/24
Final drive : Chain; Front sprocket 15; Rear sprocket 42
Wheel travel (front/rear) : 120 mm (4.7 in) - 130 mm (5.1 in)
Rake : 24,5
Front wheel trail :100 mm (3,94 in)
