ECO, Standard, High, MTB, Extra-Power, Automatic, Walk Assist
Stem
Alloy 4-both faceplate
35.0 diameter
40mm length
Handlebar
Alloy
35.0 diameter
780mm width
30mm rise
Fork
ROCKSHOX LYRIK SELECT
160mm TRAVEL
35mm Stanchions
Compatible with RockShox premium short fender
Upgradeable to new Pressure Relief Values via RockShox
Seatpost
RANZX dropper post 30.9 dia.
TRAVEL (S) 125mm (M) 150mm (L) 170m
Collar : Single-bolt 35.0mm
Grip
VELO Single Ring Lock
Chain
KMC eTURBO EPT 122 links
Shifters
Shimano XT SL-M8100-R
Saddle
YAMAHA anti-slip finish with hand rail tail
Headset
Integrated tapered 1 1/8” - 1 1/2” (30mm of spacers)
Derailleur : Rear
Shimano XT RD-M8100-SGS
Hub : Front
Anodized Alloy
Centerlock brake mount
15x110mm BOOST+ (front)
12x148mm MicroSpline freehub
Quick Release Thru Axle Type
Spoke
14g alloy SUS304
Cassette
Shimano XT CS-M8100-12
12-spd (10-51T)
Motor Details
YAMAHA PW-X3 Class 1 Labeled Centermount
ISIS Splined Crankarm Spindle
YAMAHA Quad Sensor with Automatic Support and Walk Assist Modes
Rate power: 250W (nominal), 500W (maximum)
Charging Time
1-hour 80%, 4-hour 100%
Electricals
Charger
Charger RC damper with Low-speed Compression and Reboundadjust
