light, forged aluminum cranks with a length of 150 mm and small pedal spacing (Q-factor)
Narrow wide direct mount chainring 28T
Cassette with 11 to 42 teeth
Fiber reinforced nylon platform pedals
with Cr-Mo axle and sealed industrial ball bearings
Stem
forged aluminum
CNC processed
Handlebars attached with two clamps
+/-15° flip-flop design to adjust handlebar height
Length: 50mm
Handlebar
Wide, ergonomically adapted and light aluminum handlebars for better control over the bike
sandblasted and silver anodized
Width: 680mm
Rise: 20mm
Fork
Hydraulic air suspension fork with adjustable compression and rebound damping and lockout function, 90 mm spring travel
1 1/8″ – 1″ baby taper shank
Thru axle 100 x 15 mm
Postmount mount for disc brakes
Seat
made of aluminium
secured against twisting
Seatpost
27.2x300mm
anodized aluminum seat post with display of the maximum permissible extension
Shifters
SRAM NX trigger shifter
Saddle
ergonomically adapted to the child's pelvic bones
lateral protection for leaning against house walls
Derailleur : Rear
SRAM NX rear derailleur
Motor Details
Fazua evation propulsion system
250 watt motor power
250 Wh battery capacity
55 Nm torque
Assistance up to 20 km/h
three support levels
Removable motor-battery unit (3.3 kg), down tube cover available separately from Fazua
Adjustment of various settings via the Fazua Rider app
Brakes
Front Brake
Promax hydraulic disc brakes
Disc diameter front/rear: 160/140 mm
Ergonomically fitting brake lever for small children's hands
Chassis and Suspension
Frame
Frame material: lightweight, high-quality machined 6061-T6 aluminum with butted and hydroformed tubes
26″ wheel size
sporty handling: low entry, low center of gravity and long wheelbase ensure safe handling as well as good balance and great driving pleasure
Tyres
Wheels / Rim
super light woom OFF DISCO TEC double chamber aluminum rims
Aluminum hubs with sealed cartridge bearings
Thru-axles for maximum rigidity (100 x 15 mm at the front / 135 x 12 mm at the rear)
20 G14 spokes, double crossed
aluminum nipples
Front Tyre
26 x 2.35″ Schwalbe Rocket Ron with ADDIX SPEED rubber compound
high-quality MTB tires with low rolling resistance, maximum grip, good cushioning and durability
Car valves for easy filling at any gas station
Dimensions
Weight
17kg
Accessories
4 mm Allen key for stem and seat clamp
8 mm Allen key for front wheel and pedals
