SR Suntour, NEX E25-HLO, Lockout, Steel spring, Travel= 50 mm, Aluminium steerer tube 1 1/8" - 1 1/2" tapered
Seatpost
Patent suspension, 31.6 mm, Aluminium
Grip
Herrmans, Click Ergo - lock on grips
Pedals
VP, E461, Aluminium, with Reflector
Chain
Gates, CarbonDrive
Gear
Shimano Nexus
Saddle
Selle Royal, Viento
Headset
Feimin, A-Head Tapered, ball bearing
Hub : Front
Aluminium hub, Centerlock
Hub : Rear
Shimano, Nexus
Spoke
Stainless spokes, black
Chainrings
Gates, Aluminium, 50 teeth
Sprocket
Gates, sprocket, 24 - teeth
Bottom Bracket
Integrated in the motor
Stand
Ursus, Mooi, Rear stand
Motor Details
Bosch, Active Plus, 250 W
Display
Bosch, Intuvia
Electricals
Battery
Bosch, PowerTube, 500 Wh
Head Lamp
Busch & Müller, Upp, 30 lm
Tail Lamp
AXA, Blueline
Brakes
Front Brake
Shimano, M445, 160 mm, 2-piston disc brake
Rear Brake
Shimano, M445, 160 mm, 2-piston disc brake
Brake Lever
Shimano, T445, Aluminium
Chassis and Suspension
Frame
Winora, Aluminium 6061, Aluminium 6061, Quick-release 5 x 135mm, Disc brake Post Mount
Tyres
Wheels / Rim
Ryde, Zac421, hollow rim, Aluminium
Front Tyre
Schwalbe, Marathon, 47-622, 28" x 1.75"
Rear Tyre
Schwalbe, Marathon, 47-622, 28" x 1.75"
Tube
Dunlop valve
Dimensions
Weight
25.5kg
Additional Details
Carrier : Racktime, RT-336, 25.0 kg
Lock : Abus, upgradable over Plus System
Clamping Ring : Quick release, 34.9 mm
Fenders : RPZ, Evo, Chromoplastics
Crank Arm : Winora, forged, Aluminium
Shift Lever : Shimano, Nexus, Twist shifter, 8 speed
Dynamo : via system battery
