SR Suntour, NEX E25, Steel spring, Travel= 50 mm, Aluminium steerer tube 1 1/8" - 1 1/2" tapered
Seatpost
Aluminium, Patent suspension, 31.6 mm
Grip
Herrmans, Click Ergo - lock on grips
Pedals
VP, E461, Aluminium, with Reflector
Chain
KMC, Z1 Narrow EPT
Shifters
Shimano, Nexus, Twist shifter, 7 Speed
Gear
Shimano, Nexus
Saddle
Selle Royal, Viento
Headset
Feimin, A-Head Tapered, Ball bearing
Hub : Front
Alu hub
Hub : Rear
Alu hub
Spoke
Stainless spokes
Chainrings
KMC, Steel, 38 teeth
Sprocket
Pinion, 19 teeth
Bottom Bracket
Integrated in the motor
Stand
Ursus, Mooi , Rear stand
Motor Details
Bosch, Active, 250W
Display
Bosch, Intuvia
Electricals
Battery
Bosch, PowerTube, 500 Wh
Head Lamp
Busch & Müller, Upp, 30 lm
Tail Lamp
AXA, Blueline
Brakes
Front Brake
Magura, HS11, Hydraulic rim brake
Rear Brake
Magura, HS11, Hydraulic rim brake
Brake Lever
Magura, HS11
Chassis and Suspension
Frame
Winora, Aluminium 6061, Aluminium 6061
Tyres
Wheels / Rim
Ryde, Zac421, hollow rim, Aluminium
Front Tyre
Schwalbe, Road Cruiser , 42-622, 28" x 1.6"
Rear Tyre
Schwalbe, Road Cruiser , 42-622, 28" x 1.6"
Tube
Dunlop valve
Dimensions
Weight
25.7kg
Additional Details
Crank Arm : Winora, forged, Aluminium
Clamping Ring : Quick release, 34.9 mm
Chain Guard : Horn, Catena 18
Dynamo : via system battery
Carrier : Racktime, RT-336, 25.0 kg
Fenders : RPZ, Evo, Chromoplastics
Lock : Abus, upgradable over Plus System
