Vehicle Type | Bicycle |
Stem | I - VWR, bore 25.4MM, steerer 28.6MM, 3D forged, 7degree, black, plus 31.8mm bore version to suit included riser bars
II - VWR, bore 25.4mm, steerer 28.6mm, 3D forged, 7degree, |
Handlebar | I - Humpert Horn bar (25.4 B) 580mm, black, adjustable, with grip, plus alternate riser bar UNO AL-020 58/60/64cm
II - Humpert Horn bar (25.4 B) 580mm, black, adjustable |
Fork | Front Fork : 1-1/8″ full Cr-Mo, butted, threadless, disc brake reinforced, lowrider & electric cable mounts, steering stabilizer mount |
Seatpost | Kalloy SP-342 micro adjust 27.2 × 300mm silver, Kalloy, SC-200 black |
Grip | I - Humpert high density foam. Separate grips for included riser bar.
II - Humpert high density foam |
Crankset | I - FSA VERO, 130 BCD, Black 165/170/175mm or Andel RSC1-5121-RL, Black, 130 BCD
II - Andel RSC1-5121-RL, Black, 130 BCD, 165mm/170mm/175mm
Crank Fixing Bolts : FSA QR-1, Self-Extracting, cr-mo, M8 (tools in tool kit) |
Pedals | VP-R62, single sided clipless, with cleats |
Chain | Chain Guard : Hebie Chainglider 42T/16-17T, black |
Shifters | Rohloff right hand 14 speed twist shifter |
Saddle | VWR custom, black, with cut-out 270mm x 168mm |
Headset | Tange RDC-82, 1-1/8″, Duralumnium, black, stack 26.2, fully sealed cartridge, 81gms; 10mmx9 + 5mmx1 + 3mmx1 |
Hub : Front | Rohloff speedhub 500/14, 36H, CC DB, black, external transfer bo 210 degree, OEM axle plate, with spoke ring |
Hub : Rear | Dynamo hub, KT, black , (6-bolt), 6V 3W, 36H, |
Spoke | Front Spokes : I - DT Champion 32H, silver, cross three pattern, 14G (2.0MM)
I - Sapim Leader 32H, silver, cross three pattern, 14G (2.0mm) with Sapim Polyax brass nipples
Rear Spokes : I - DT Competition double butted, 32, silver, cross two pattern, 14/15/14G (2.0/1.8/2.0mm)
II - Sapim Leader 32H, silver, cross three pattern, 14G (2.0mm) with Sapim Polyax brass nipples |
Sprocket | Rear Sprocket : Gates CDX 19T |
Bottom Bracket | Shimano UN55 English square taper JIS sealed cartridge 68mm x 118mm |
