Vehicle Type | Bicycle |
Stem | VWR, bore 31.8MM, steerer 28.6MM, 3D forged, 7degree , 60(XS)/80(S)/100(M)/120(L,XL)/130(XXL)MM, black |
Handlebar | Zoom NR-AL-196BT 180 swept back riser bar (31.8 B) 700mm, black, 25mm rise |
Fork | Front Fork : 1-1/8″ full Cr-Mo, butted, threadless, disc brake reinforced, lowrider & electric cable mounts, steering stabilizer mount |
Seatpost | Satori alloy micro adjust 27.2 X 300mm silver, Satori black |
Grip | Propalm HY-859-3A, black |
Crankset | Andel RSC1-5121-RL, Black, 130 BCD, 165mm/170mm/175mm
Crank Fixing Bolts : FSA QR-1, Self-Extracting, cr-mo, M8 (tools in tool kit) |
Pedals | VP-R62, single sided clipless, with cleats |
Shifters | Shift Levers : Rohloff right hand 14 speed twist shifter |
Saddle | VWR custom, black, with cut-out 270mm x 168mm |
Headset | Tange RDC-82, 1-1/8″, Duralumnium, black, stack 26.2, fully sealed cartridge, 81gms; 10mmx9 + 5mmx1 + 3mmx1 |
Hub : Front | Rohloff speedhub 500/14, 36H, CC DB, black, external transfer bo 210 degree, OEM axle plate, with spoke ring |
Hub : Rear | Dynamo hub, KT, black , (6-bolt), 6V 3W, 36H, OLD:100mm, Formula QR23 (internal cam type) |
Spoke | Front Spokes : Sapim Leader 32H, silver, cross three pattern, 14G (2.0mm) with Sapim Polyax brass nipples |
Sprocket | Rear Sprocket : Gates CDX 19T |
Bottom Bracket | Genio Eccentric Bottom Bracket
Shimano UN55 English square taper JIS sealed cartridge 68mm x 118mm |
