Vehicle Type | Bicycle |
Stem | VWR, bore 25.4mm, steerer 28.6mm, 3D forged, 7degree , 60(XS)/80(S)/100(M)/120(L,XL)/130(XXL)mm, black |
Handlebar | Humpert Horn bar (25.4 B) 580mm, black, adjustable |
Fork | Front Fork : 1-1/8″ full Cr-Mo, 12mm through axle, threadless, disc brake reinforced, lowrider & electric cable mounts, steering stabilizer mount, extra waterbottle cage mount |
Seatpost | Kalloy SP-342 micro adjust 27.2 × 300mm silver, Kalloy, SC-200 black |
Grip | Humpert high density foam |
Crankset | Sugino triple CW&C, 48/36/24, 165/170/175MM, 110/74MM PCD, suit 9speed |
Pedals | VP-R62, single sided clipless, with cleats |
Chain | KMC X9, 1/2″ × 11/128″ np/np 116L 9 Speed |
Shifters | Shift Levers : Shimano Alivio M-4000, 9-speed trigger |
Saddle | VWR custom, black, with cut-out 270mm x 168mm |
Headset | Tange RDC-82, 1-1/8″, Duralumnium, black, stack 26.2, fully sealed cartridge, 81gms; 10mmx9 + 5mmx1 + 3mmx1 |
Derailleur : Front | FD-T4000-9, Alivio 63~66, Top-Swing, Dual-Pull, FOR 9-Speed |
Derailleur : Rear | Shimano DEORE, RD-M592-SGS 9-speed |
Hub : Front | Dynamo Hub JH-KD5F, 12×100, 32H, Black, 6-Bolt Mount , 6V3W |
Hub : Rear | Shimano Deore XT freehub, FH-M756A L 32H 8/9/10-speed, for disc brake (6 bolt), black |
Spoke | Front Spokes : DT Champion 32H, silver, cross three pattern, 14G (2.0MM)
Rear Spokes : DT Alpine III triple butted, 36, silver, cross three pattern, 13/15/14G (2.34/1.8/2.0mm) |
Cassette | Shimano CS-HG400-9, 9-speed Ni-plated 11-34T |
Bottom Bracket | Shimano UN55 English square taper JIS sealed cartridge 68mm x 111mm |
