Vehicle Type | Bicycle |
Load Carrying Capacity | Combined weight of bicycle, rider, and cargo of 300 pounds (136 kg) |
Stem | Size : S, M - OCLV Carbon, 0 mm handlebar rise, 750 mm width, -13 degree stem rise, 70 mm length
Size : M, L - OCLV Carbon, 0 mm handlebar rise, 750 mm width, -13 degree stem rise, 80 mm length
Size : XL - OCLV Carbon, 0 mm handlebar rise, 750 mm width, -13 degree stem rise, 90 mm length |
Handlebar | Bontrager RSL Integrated handlebar |
Fork | Fox Performance 32 Step-Cast, Float EVOL air spring, GRIP 2-position damper, remote lockout, tapered steerer, 44 mm offset, Boost110, 15 mm Kabolt axle, 100 mm travel |
Seatpost | Size : S - Bontrager Pro, OCLV Carbon, 31.6 mm, 0 mm offset, 330 mm length
Size : M, L, XL - Bontrager Pro, OCLV Carbon, 31.6 mm, 0 mm offset, 400 mm length |
Grip | ESI Chunky |
Chain | SRAM GX Eagle, 12 speed |
Shifters | SRAM GX Eagle AXS, 12 speed |
Saddle | Bontrager P3 Verse Elite, stainless steel rails, 145 mm width |
Headset | Knock Block Integrated, 62-degree radius, cartridge bearing, 1-1/8'' top, 1.5'' bottom |
Derailleur : Rear | SRAM GX Eagle AXS |
Cassette | SRAM Eagle XG-1275, 10-52, 12 speed |
Bottom Bracket | SRAM DUB, 92 mm, PressFit |
Tyres |
---|
Wheels / Rim | Front : Bontrager Kovee Pro 30 carbon, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle
Rear : Bontrager Kovee Pro 30 carbon, Tubeless Ready, Rapid Drive 108, 6-bolt, SRAM XD driver, Boost148, 12 mm thru axle |
Front Tyre | Bontrager XR2 Team Issue, Tubeless Ready, Inner Strength sidewall, aramid bead, 120 tpi, 29 x 2.20'' |
Rear Tyre | Bontrager XR2 Team Issue, Tubeless Ready, Inner Strength sidewall, aramid bead, 120 tpi, 29 x 2.20'' |
