Vehicle Type | Bicycle |
Load Carrying Capacity | Combined weight of bicycle, rider, and cargo of 300 pounds (136 kg) |
Stem | Bontrager Line Pro, 35 mm, Knock Block, Blendr compatible, 0 degree, 35 mm length |
Handlebar | Bontrager Line Pro, OCLV Carbon, 35 mm, 27.5 mm rise, 820 mm width |
Fork | RockShox ZEB Select+, DebonAir spring, Charger 2.1 RC damper, tapered steerer, 44 mm offset, Boost110, 15 mm Maxle Stealth, 170 mm travel |
Seatpost | Size : S - Bontrager Line Elite Dropper, 100 mm travel, MaxFlow, internal routing, 34.9 mm, 345 mm length
Size : M, M/L - Bontrager Line Elite Dropper, 150 mm travel, MaxFlow, internal routing, 34.9 mm, 440 mm length
Size : L - Bontrager Line Elite Dropper, 170 mm travel, MaxFlow, internal routing, 34.9 mm, 485 mm length
Size : XL - Bontrager Line Elite Dropper, 200 mm travel, MaxFlow, internal routing, 34.9 mm, 550 mm length |
Grip | Bontrager XR Trail Pro, alloy lock-on |
Crankset | Size : S - SRAM GX Eagle, DUB MTB Wide, 30T, Boost (55 mm chainline), 170 length
Size : M, M/L, L, XL - SRAM GX Eagle, DUB MTB Wide, 30T, Boost (55 mm chainline), 175 length |
Chain | SRAM GX Eagle, 12 speed |
Shifters | SRAM GX Eagle, 12 speed |
Saddle | Bontrager Arvada, austenite rails, 138 mm width |
Headset | Knock Block 2.0 Integrated, 72-degree radius (includes infinite-radius chip), sealed cartridge bearing, 1-1/8'' top, 1.5'' bottom |
Derailleur : Rear | SRAM GX Eagle |
Hub : Front | Bontrager alloy, sealed bearing, 6-bolt, 108T Rapid Drive, SRAM XD driver, Boost148, 12 mm thru axle |
Hub : Rear | Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15 mm thru axle |
Cassette | SRAM Eagle XG-1275, 10-52, 12 speed |
Chainrings | Max: 34T, Min 28T |
Bottom Bracket | SRAM DUB, 73 mm, BSA threaded |
Tyres |
---|
Wheels / Rim | Front : NEW Bontrager Line Elite 30, OCLV Mountain Carbon, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle
Rear : Bontrager Line Elite 30, OCLV Mountain Carbon, Tubeless Ready, Rapid Drive 108, 6-bolt, SRAM XD driver, Boost148, 12 mm thru axle |
Front Tyre | Bontrager SE4 Team Issue, Tubeless Ready, Core Strength sidewall, aramid bead, 60 tpi, 29 x 2.40'' |
Rear Tyre | Bontrager SE5 Team Issue, Tubeless Ready, Core Strength sidewall, aramid bead, 60 tpi, 29 x 2.60'' |
