Vehicle Type | Bicycle |
Load Carrying Capacity | Combined weight of bicycle, rider, and cargo of 300 pounds (136 kg) |
Stem | Size : XS, S, M - Bontrager alloy, 31.8 mm, Blendr compatible, 7 degree, 50 mm length
Size : M/L, L, XL - Bontrager alloy, 31.8 mm, Blendr compatible, 7 degree, 60 mm length |
Handlebar | Size : XS - Bontrager alloy, 31.8 mm, 15 mm rise, 720 mm width
Size : S, M, M/L, L, XL - Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width |
Fork | SR Suntour XCM 32, coil spring, preload, lockout, 47 mm offset, Boost110, 15 mm thru axle, 120 mm travel |
Seatpost | Size : XS, S, M - TranzX JD-YSP18, 100 mm travel, internal routing, 31.6 mm, 361 mm length
Size : M/L, L, XL - TranzX JD-YSP18, 130 mm travel, internal routing, 31.6 mm, 425 mm length |
Grip | Bontrager XR Trail Comp, nylon lock-on |
Crankset | Size : XS, S - FSA Alpha Drive, 28T steel ring, Boost, 170 mm length
Size : M, M/L, L, XL - FSA Alpha Drive, 28T steel ring, Boost, 175 mm length |
Pedals | VP-536 nylon platform |
Chain | KMC X10, 10 speed |
Shifters | Shimano Deore M4100, 10 speed |
Saddle | Bontrager Arvada, steel rails, 138 mm width |
Headset | Semi-integrated, cartridge, 1-1/8'' top, 1.5'' bottom |
Derailleur : Rear | Shimano Deore M5120, long cage |
Hub : Front | Formula DC-2241, alloy, 6-bolt, Shimano 8/9/10 freehub, Boost141, 5 mm QR |
Hub : Rear | Formula DC-511, 6-bolt, Boost110, 15 mm thru axle |
Spoke | 14g stainless steel |
Cassette | Shimano Deore M4100, 11-46, 10 speed |
Bottom Bracket | Shimano 7420ST, 73 mm, threaded cartridge, 124.5 mm spindle |
