Vehicle Type | Bicycle |
Stem | Size: XXS , XS , S
Bontrager Comp, 31.8 mm, 7-degree, 35 mm length
Size: M , ML , L
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length
Size: XL
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 60 mm length
Size: XXL
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 70 mm length |
Handlebar | Size: XXS , XS
Bontrager alloy, 31.8 mm, 5 mm rise, 690 mm width
Size: S
Bontrager alloy, 31.8 mm, 15 mm rise, 720 mm width
Size: M , ML , L , XL , XXL
Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width |
Fork | Size: XXS -
RockShox Judy Silver, Solo Air spring, rebound adjust, TurnKey hydraulic lockout, 42 mm offset for 27.5" wheel, 100 mm QR, 80 mm travel
Size: XS , S -
RockShox Judy Silver, Solo Air spring, rebound adjust, TurnKey hydraulic lockout, 42 mm offset for 27.5" wheel, 100 mm QR, 100 mm travel
Size: M , ML , L , XL , XXL -
RockShox Judy Silver, Solo Air spring, rebound adjust, TurnKey hydraulic lockout, 46 mm offset for 29" wheel, 100 mm QR, 100 mm travel |
Seatpost | Size: XXS , XS , S
TranzX JD-YSP18, 100 mm travel, internal routing, 31.6 mm, 361 mm length
Size: M
TranzX JD-YSP18, 130mm travel, internal routing, 31.6 mm, 425 mm length
Size: ML , L , XL , XXL
TranzX JD-YSP18, 150 mm travel, internal routing, 31.6 mm, 470 mm length |
Grip | Bontrager XR Trail Comp, nylon lock-on |
Crankset | Size: XXS
SRAM SX Eagle, 30T steel ring, 49 mm chainline, 155 mm length
Size: XS , S , M
SRAM SX Eagle, 30T steel ring, 49 mm chainline, 170 mm length
Size: ML , L , XL , XXL
SRAM SX Eagle, 30T steel ring, 49 mm chainline, 175 mm length |
Pedals | VP-536 nylon platform |
Chain | SRAM SX Eagle, 12-speed |
Shifters | SRAM SX Eagle, 12-speed |
Saddle | Bontrager Arvada, steel rails, 138 mm width |
Headset | Semi-integrated, 1-1/8" |
Derailleur : Rear | SRAM SX Eagle |
Hub : Front | Formula DC-20 LW, alloy, 6-bolt, 5x100 mm QR |
Hub : Rear | Formula DC-22LW, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR |
Cassette | SRAM PG-1210 Eagle, 11-50, 12-speed |
Chainrings | 1x: 34T, 2x: 36/22 |
Bottom Bracket | Truvativ Powerspline, 73 mm, threaded cartridge, 118 mm spindle |
Tyres |
---|
Wheels / Rim | Size: XXS , XS , S -
Bontrager Kovee, double-wall, Tubeless Ready, 28-hole, 23 mm width, Presta valve
Size: M , ML , L , XL , XXL -
Bontrager Kovee, double-wall, Tubeless-Ready, 28-hole, 23 mm width, Presta valve |
Front Tyre | Size: XXS
Maxxis Ardent, tubeless ready, EXO casing, folding bead, 60tpi, 26x2.40"
Size: XS , S
Maxxis Ardent, tubeless ready, EXO casing, folding bead, 60tpi, 27.5x2.40"
Size: M , ML , L , XL , XXL
Maxxis Ardent, tubeless ready, EXO casing, folding bead, 60tpi, 29x2.40" |
Rear Tyre | Size: XXS
Maxxis Ardent, tubeless ready, EXO casing, folding bead, 60tpi, 26x2.40"
Size: XS , S
Maxxis Ardent, tubeless ready, EXO casing, folding bead, 60tpi, 27.5x2.40"
Size: M , ML , L , XL , XXL
Maxxis Ardent, tubeless ready, EXO casing, folding bead, 60tpi, 29x2.40" |
