Vehicle Type | Bicycle |
Load Carrying Capacity | Combined weight of bicycle, rider, and cargo of 300 pounds (136 kg) |
Stem | Size : S - Bontrager Elite, 31.8 mm, Blendr compatible, 7 degree, 60 mm length
Size : M - Bontrager Elite, 31.8 mm, Blendr compatible, 7 degree, 70 mm length
Size : L - Bontrager Elite, 31.8 mm, Blendr compatible, 7 degree, 80 mm length
Size : XL - Bontrager Elite, 31.8 mm, Blendr compatible, 7 degree, 90 mm length |
Handlebar | Bontrager Rhythm Comp, alloy, 31.8 mm, 15 mm rise, 750 mm width |
Fork | Bontrager Haru, tapered alloy steerer, OCLV Carbon lowers, 490 mm axle-to-crown, 15 x 150 mm thru axle |
Seatpost | Size : S - TranzX JD-YSP18, 100 mm travel, internal routing, 31.6 mm, 361 mm length
Size : M - TranzX JD-YSP18, 120 mm travel, internal routing, 31.6 mm, 403 mm length
Size : L, XL - TranzX JD-YSP18, 130 mm travel, internal routing, 31.6 mm, 425 mm length |
Grip | Bontrager XR Trail Elite, alloy lock-on |
Crankset | Size : S - SRAM GX Eagle, DUB, 30T alloy FAT 5 ring, 170 mm length
Size : M, L, XL - SRAM GX Eagle, DUB, 30T alloy FAT 5 ring, 175 mm length |
Pedals | VP-536 nylon platform |
Chain | SRAM GX Eagle, 12 speed |
Shifters | SRAM GX Eagle, 12 speed |
Saddle | Bontrager Arvada, hollow chromoly rails, 138 mm width |
Headset | FSA IS-2, 1-1/8'' top, 1.5'' bottom |
Derailleur : Rear | SRAM GX Eagle |
Hub : Front | Bontrager alloy, sealed bearing, 6-bolt, 108T Rapid Drive, SRAM XD driver, 197 x 12 mm thru axle |
Hub : Rear | Bontrager alloy, sealed bearing, 6-bolt, 15 x 150 mm thru axle |
Spoke | 15g stainless steel |
Cassette | SRAM Eagle XG-1275, 10-52, 12 speed |
Chainrings | 1x: 32T, 2x: 22/36 |
Bottom Bracket | SRAM DUB, 121 mm, PressFit |
