Vehicle Type | Bicycle |
Load Carrying Capacity | Combined weight of bicycle, rider, and cargo of 300 pounds (136 kg) |
Stem | Size : S - Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 60 mm length
Size : M - Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 70 mm length
Size : L - Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 80 mm length
Size : XL - Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 90 mm length |
Handlebar | Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width |
Fork | Manitou Mastodon 34 Comp, air spring, ABS damper, lockout, tapered steerer, 51 mm offset, 150 x 15 mm thru axle, 80 mm travel |
Seatpost | Size : S - TranzX JD-YSP18, 100 mm travel, internal routing, 31.6 mm, 361 mm length
Size : M, L, XL - TranzX JD-YSP18, 130 mm travel, internal routing, 31.6 mm, 425 mm length |
Grip | Bontrager XR Trail Comp, nylon lock-on |
Crankset | Size : S - SRAM X1 1000 Eagle, DUB, 30T alloy FAT 5 ring, 170 mm length
Size : M, L, XL - SRAM X1 1000 Eagle, DUB, 30T alloy FAT 5 ring, 175 mm length |
Pedals | VP-536 nylon platform |
Chain | SRAM SX Eagle, 12 speed |
Shifters | SRAM SX Eagle, 12 speed |
Saddle | Bontrager Arvada, steel rails, 138 mm width |
Headset | FSA IS-2, 1-1/8'' top, 1.5'' bottom |
Derailleur : Rear | SRAM NX Eagle |
Hub : Front | Bontrager alloy, sealed bearing, 6-bolt, Rapid Drive 108, Shimano 10 freehub, 197 x 12 mm thru axle |
Hub : Rear | Bontrager alloy, sealed bearing, 6-bolt, 15 x 150 mm thru axle |
Spoke | 15g stainless steel |
Cassette | SRAM PG-1210 Eagle, 11-50, 12 speed |
Chainrings | 1x: 32T, 2x: 22/36 |
Bottom Bracket | SRAM DUB, 121 mm, PressFit |
Tyres |
---|
Wheels / Rim | SUNRingle Mulefut 80 SL, 32-hole cutout |
Front Tyre | Bontrager Gnarwhal Team Issue, Tubeless Ready, Inner Strength sidewalls, studdable, aramid bead, 120 tpi, 27.5 x 4.50'' |
Rear Tyre | Bontrager Gnarwhal Team Issue, Tubeless Ready, Inner Strength sidewalls, studdable, aramid bead, 120 tpi, 27.5 x 4.50'' |
