Book a Test Drive through Bikes4Sale and we will try to get you the best offer for Tern Vektron P9.
| Vehicle Type | Bicycle |
| Fuel | Electric |
| Maximum Torque | 80 NM |
| Top Speed | 25 kmph |
| Stem | Tern Andros (G2), adjustable, forged construction, patented technology |
| Handlebar | Flat bar, 6061-Al, Tern Andros adapted |
| Fork | Tern Tarsus, 6061-Al, hydroformed |
| Seatpost | Tern Telescope, 34.9 mm, Lite 2014-AL SEATPOST CLAMP : Oversize, 6061-Al, 2 pc |
| Grip | BioLogic Arx |
| Crankset | Vektron custom, forged 6061-AL crankarm |
| Pedals | LiteForm QR, alloy body, QR right/standard left |
| Chain | 9 spd, DHT for eBike, GST corrosion resistant coating |
| Shifters | Shimano, 1 x 9 spd, trigger |
| Saddle | Tern Porter, patented GripPad design |
| Headset | Tern Flux, cartridge bearings, Physis integrated |
| Derailleur : Rear | Shimano Sora |
| Hub : Front | Shimano disc |
| Hub : Rear | Shimano disc |
| Spoke | Stainless steel |
| Cassette | Shimano 11-32T, 9 spd |
| Motor Details |
|---|
| Bafang M400 Drive System, 36 V/250 W, max speed 25 kph (EU); max speed 20 mph (US), max torque 80 Nm |
| Range |
|---|
| 40-90 km (25-56 mi) |
| Display |
|---|
| Bafang M400 Drive System Display, 5 mode selectable, walk assist |
| Electricals | |
|---|---|
| Battery | Bafang M400 Drive System Battery, 400 Wh, Panasonic cells |
| Charger | Bafang Charger |
| Head Lamp | Tern Valo Direct, integrated, 41 lux/150 lumens |
| Tail Lamp | Herrmans H-Trace / H-Trace Mini, for eBike |
| Brakes | |
|---|---|
| Front Brake | Shimano, hydraulic disc |
| Rear Brake | Shimano, hydraulic disc |
| Brake Lever | Shimano, hydraulic disc |
| Chassis and Suspension | |
|---|---|
| Frame | Tern Vektron, hydroformed aluminum, OCL+ joint, 3 patented technologies |
| Tyres | |
|---|---|
| Wheels / Rim | WHEEL SIZE : 20" wheels RIMS : Kinetix Comp, for disc |
| Front Tyre | Schwalbe Big Apple, Performance Line, 55-406, puncture protection, Reflex |
| Rear Tyre | Schwalbe Big Apple, Performance Line, 55-406, puncture protection, Reflex |
| Dimensions | |
|---|---|
| Weight | 22.6 kg |
| Accessories |
|---|
| Pedal Holder |
| Additional Details |
|---|
| HANDLEPOST : Tern Physis 3D (G2), 3D forged, 5 patented technologies, 12°, 320 mm FOLDING SIZE : 41 x 86 x 68 cm (16.1" x 33.9" x 26.8") FOLDING TIME : 10 sec FRAME SIZES : One size GEAR INCHES : 33" - 97" (2.65 - 7.72 m) DISTANCE: SEATPOST TO HANDLEBAR : Min. 620 mm (24.4") Max: 690 mm (27.2") DISTANCE: SADDLE TO PEDAL : Min. 680 mm (26.8") Max: 1110 mm (43.7") SUGGESTED RIDER HEIGHT : 147 - 195 cm (4'10" - 6'5") MAX LOAD WEIGHT : 105 kg (230 lb) SHIFTER CABLE & HOUSING: Jagwire LEX-SL, slick treatment, alloy ferrules BOTTOM BRACKET: Motor integrated KICKSTAND : DoubleStand, center mount CLIP SYSTEM : Magnetix 2.0 FENDERS : SplashGuard, stainless hardware RACK(S) : Opt: Tern Cargo Rack |
