Not Available
Book a Test Drive through Bikes4Sale and we will try to get you the best offer for Tern GSD S00 LX.
Beetle Blue
Rhino Grey
| Vehicle Type | Bicycle |
| Fuel | Electric |
| Stem | Tern Andros, adjustable, forged construction, patented technology |
| Handlebar | Tern Sweep, 6061-AL, Tern Andros adapted |
| Fork | Suntour custom for Tern, 1.5" tapered Chromoly steerer, 32 mm stanchions, Thru-axle, 70 mm travel, EFBE approved: 200 kg |
| Seatpost | Cane Creek Thudbuster G4, Tern Telescope, 34.9/30.9 mm |
| Grip | Ergon |
| Crankset | Tern GSD custom, Gates CDX CNC machined beltring |
| Pedals | Urban with non-slip surface, sealed bearings |
| Chain | Gates Carbon Drive CDX belt |
| Shifters | Enviolo, Twist |
| Saddle | Tern GSD by Velo, with rear handle |
| Headset | Tern Flux Pro Taper, 1.5", angular contact bearings, Physis integrated |
| Hub : Front | Tern Atlas, Boost Thru-Axle, Cargo-optimized design, sealed cartridge bearing |
| Hub : Rear | Enviolo SP, 380% continuously variable range, Boost |
| Spoke | Stainless steel, 13G |
| Cassette | Gates CDX, precision CNC machined cog |
| Motor Details |
|---|
| Bosch Cargo Line, 400% Assist, 85 Nm Torque, max speed 25 kph (EU); max speed 20 mph (US) |
| Range |
|---|
| 500 Wh: 50-101 km (31-63 mi); 1000 Wh: 102-206 km (63-128 mi) |
| Display |
|---|
| Bosch Purion, 4 mode selectable, walk assist |
| Electricals | |
|---|---|
| Battery | Bosch Dual Battery system, 500 Wh or 1000 Wh |
| Charger | 220V, 4A (EU); 100-240V, 4A (US) |
| Head Lamp | Ignis Headlight, Ultra wide 700 lumens, Hi/Lo Beam |
| Tail Lamp | RearStop Brake Light, Always on brake light |
| Brakes | |
|---|---|
| Front Brake | Magura MT5, 4-piston hydraulic disc, 180 mm rotor, Sport pads |
| Rear Brake | Magura MT5, 4-piston hydraulic disc, 180 mm rotor, Sport pads |
| Brake Lever | Magura MT5 e-stop, hydraulic, with brake sensor |
| Chassis and Suspension | |
|---|---|
| Frame | Tern GSD, 6061-AL, patented MultiTruss design, EFBE Tri-Test approved: 200 kg |
| Tyres | |
|---|---|
| Wheels / Rim | 20" wheels Tern Atlas, ultra wide 36 mm, dual reinforced joint |
| Front Tyre | Schwalbe Big Ben Plus, 55-406, Green Guard puncture protection, Reflex |
| Rear Tyre | Tern x Schwalbe Super Moto-X, 62-406, Green Guard puncture protection, Reflex |
| Dimensions | |
|---|---|
| Weight | 34.8 kg |
| Accessories |
|---|
| SPEEDS : Continuously Variable 380% FENDERS : Integrated Wheel Guard, AL6061, w/ Side Skirt RACK(S) : Frame integrated, heavy duty design ABUS, keyed-alike with Bosch battery |
| Additional Details |
|---|
| FOLDING SIZE : 176 x 40.5 x 87 cm (69.3" x 15.9" x 34.3") FOLDING TIME : 5 sec FRAME SIZES : 186 cm (Total Length) GEAR INCHES : 26" - 99" (2.08 - 7.91 m) DISTANCE: SEATPOST TO HANDLEBAR : Min: 490 mm (19.3") Max: 590 mm (22") DISTANCE: SADDLE TO PEDAL : Min: 690 mm (27.2") Max: 1050 mm (41.3") SUGGESTED RIDER HEIGHT : 150 - 195 cm (4'11" - 6'5") MAX GROSS VEHICLE WEIGHT : 200 kg (440 lb) MAX RIDER WEIGHT : 120 kg (264 lb) SEATPOST CLAMP : Tern Collar, 6061-AL, 2pc SHIFTER CABLE & HOUSING : Jagwire LEX-SL, slick treatment, alloy ferrules |
