Price, features and specs
Rate Surly Ghost Grappler:
Surly Ghost Grappler Price
$
1899
[Albuquerque, United States]
The given price can change depending on the colour, accessories and other features.
Country, City
Showroom Price
On Road Price
United States, Albuquerque
$ 1899
--
United States, Anchorage
$ 1899
--
United States, Atlanta
$ 1899
--
United States, Austin
$ 1899
--
United States, Baltimore
$ 1899
--
United States, Billings
$ 1899
--
United States, Birmingham
$ 1899
--
United States, Boston
$ 1899
--
United States, Bridgeport
$ 1899
--
United States, Burlington
$ 1899
--
View price in other cities
Buy new Surly Ghost Grappler
Book a Test Drive through Bikes4Sale and we will try to get you the best offer for Surly Ghost Grappler.
For Exciting Offers, Book a Test Drive
Features
Internal dropper post routing
Seatstay-mounted bottle bosses, plus three-pack mounts at the top and bottom of the down tube
Custom dropouts ready to run single-speed or internally geared hub setups
Technical Specifications
Vehicle Type Bicycle Stem Promax DA-296, 31.8 or Kalloy AS-007
Stem Angle: 6.0° Handlebar Salsa Cowchipper 31.8
Handlebar Width: 400mm Fork 100% Chromoly Steel fork, Natch tubing, double-butted tapered fork blades, TIG welded, E.D. coated
Fork Rake: 50mm
Fork Length: 420mm Seat Seat Tube Angle: 73.0°
Seat Tube Length: 316mm Seatpost TransX YSP15, 30.9, 100mm travel
30.9mm
Clamp: Surly Stainless 33.1 Grip Cork Black Crankset Samox 2PCS Boost 32t
Crank Length: 170mm Chain KMC X10 Econo Black or NP/BLK
Chainstay Length: 425mm Shifters Microshift SB-M100, AdventX Dual Control Levers Saddle WTB Volt 142 Headset Cane Creek 40 Derailleur : Rear Microshift M6205 Hub : Front Novatec 15x110mm, 32h Hub : Rear Novatec 12x148mm, 32h Bottom Bracket Samox BSA 24
Brakes Front Brake Tektro Mira MD-C400 Rear Brake Tektro Mira MD-C400 Brake Lever AdventX Dual Control Levers
Chassis and Suspension Frame 100% Chromoly Steel frame, Natch tubing, double-butted main triangle, TIG welded, E.D. coated
Tyres Wheels / Rim Rim: WTB ST i40 TCS Front Tyre Teravail Ehline, 27.5 x 2.5", 60tpi Rear Tyre Teravail Ehline, 27.5 x 2.5", 60tpi Tube Top Tube Length, Effective: 560mm
Head Tube Length: 160mm
Head Tube Angle: 69.5°
Dimensions Height 719 mm Wheelbase 1057 mm
Additional Details
Size:
XS - Rider Height - 1.42m+
SM - Rider Height - 1.52m+
MD - Rider Height - 1.65m+
LG - Rider Height - 1.75m+
XL - Rider Height - 1.85m+
Rotors: Tektro 180/160
Cog or cogset: Microshift 11-48t
BB Drop: 50mm
Stack: 585mm
Reach: 381mm
