Pinarello Dogma F Dura Ace DI2 Bicycle

Price, features and specs

Launched globally in June 2024.

Rate Pinarello Dogma F Dura Ace DI2:
3.7/5 (6 votes)
Pinarello Dogma F Dura Ace DI2 Price

Not Available

Features
Carbon M40X
Down Tube
New Aero-Keel BB
Top Tube
Headset
Thru Axles
New Onda Fork
Integrated Seat Post Clamp
New Talon Fast
Colours

Luxter Blue
Luxter Red Gold
Luxter Venice
Edge Crystal White
Black On Black
Ineos Replica
Aurik Yellow

Technical Specifications
Vehicle TypeBicycle
HandlebarMOST Talon Ultra Fast
ForkNEW eTICR Onda Fork with ForkFlap™, 1.5' upper and lower steerer
SeatpostPinarello Aero seatpost with 3D printed titanium top seatclamp and bolts
CranksetShimano Dura Ace FC-R9200, HollowTech 2, 12s
ChainShimano Dura Ace CN-HG 12S
SaddleMost Lynx Ultrafast Superflow L Carbon Large 145mm
Derailleur : FrontShimano Dura Ace Di2 FD-9200 12S
Derailleur : RearShimano Dura Ace Di2 RD-R9200 12s
CassetteShimano Dura Ace CS-R9200 12S
Bottom BracketShimano Dura Ace SM-BB9200
Brakes
Front BrakeDura Ace BR-R9200, 2 pistons caliper, 160mm rotor
Rear BrakeDura Ace BR-R9200, 2 pistons caliper, 140mm rotor
Chassis and Suspension
FrameTorayCa M40X, TiCR™ Cable Routing, Italian BB
Tyres
Wheels / RimPrinceton Peak 4550 DB
Front TyrePirelli P Zero Race 26mm - Black, 127 tpi aramid breaker. Max tyre size 28mm (width as measured)
Dimensions
Weight6.77 kg
