EXTRA WIDE CRUISER STYLE SADDLE WITH SOFT FOAM AND ADJUSTABLE BACK REST; 265MM L X 280MM W.
Headset
ZERO STACK SEMI-INTEGRATED 1 ⅛” THREADED; ZS44/28.6-26TPI | ZS44/30.
Spoke
FRONT : SILVER HEAVY DUTY 12 GAUGE STAINLESS STEEL SPOKES WITH BRASS NIPPLES.
REAR : SILVER HEAVY DUTY 13 GAUGE STAINLESS STEEL SPOKES WITH BRASS NIPPLES.
Sprocket
SHIMANO 22T 3-LOBE STAINLESS STEEL SPROCKET.
Bottom Bracket
84MM X 147MM SQUARE TAPER SPINDLE WITH SEALED CARTRIDGE BEARINGS; STEEL CUPS AND BODY.
Motor Details
SILVER 36V BRUSHLESS GEARED HUB MOTOR; 350 WATT NOMINAL POWER RATING; 35NM TORQUE; QUICK DISCONNECT CABLE WITH WATERPROOF CONNECTION.
Display
3.5” BACKLIT LCD SCREEN; 4 BUTTONS TO CONTROL ELECTRONICS, TOGGLE INFO DISPLAYED, AND CUSTOMIZE SETTINGS; USB CHARGING PORT; WATERPROOF THREADED CONNECTION; CUSTOM PEDALSENSE SOFTWARE.
Electricals
Battery
36 VOLT 11 AMP HOUR WITH PREMIUM LITHIUM ION 18650 CELLS; INTEGRATED FOLDING HANDLE FOR EASY REMOVAL; EXTERNAL LED STATE OF CHARGE INDICATOR.
WEIGHT : 5 LB
Charger
PEDEGO FANLESS 2 AMP SMART CHARGER; SEALED CASE WITH CHARGE INDICATOR LIGHT.
Controller
36 VOLT 15 AMP SINE WAVE CONTROLLER WITH CUSTOM PEDALSENSE® SOFTWARE AND WATERPROOF CONNECTIONS.
Head Lamp
LED WITH ADJUSTABLE MOUNT 40 LUX (200 LUMENS)
Tail Lamp
CARGO BUCKET MOUNTED LED
Brakes
Front Brake
SHIMANO BR-M375 MECHANICAL DISC BRAKES
Rear Brake
AVID BB7S MOUNTAIN MECHANICAL DISC BRAKES
Brake Lever
ERGONOMIC BRAKE LEVER WITH INTEGRATED PARKING BRAKE; INTEGRATED MOTOR CUT OFF SWITCH FOR MAXIMUM SAFETY.
Chassis and Suspension
Frame
6061-T6 ALUMINUM ALLOY; INTEGRATED COMPOSITE REAR CARGO BUCKET FOR STORAGE; INTERNAL CABLE AND WIRE ROUTING.
Tyres
Wheels / Rim
FRONT : 20” ALUMINUM ALLOY DOUBLE WALL RIM; 24.7MM INTERNAL WIDTH; PINNED JOINT; 3D ANGLE DRILLED SPOKE HOLES; 12G X 36 HOLE.
REAR : 20” ALUMINUM ALLOY DOUBLE WALL RIMS; 23.4MM INTERNAL WIDTH; PINNED JOINT; 13G X 36 HOLE.
Front Tyre
SCHWALBE BIG BEN 20” X 2.15” WITH RACEGUARD KEVLAR FLAT PROTECTION; SLIME INNER TUBE SEALANT; SCHRADER VALVE.
Rear Tyre
SCHWALBE BIG BEN 20” X 2.15” WITH RACEGUARD KEVLAR FLAT PROTECTION; SLIME INNER TUBE SEALANT; SCHRADER VALVE.
Dimensions
Weight
33.8kg
Additional Details
THROTTLE : TWIST AND GO THROTTLE WITH THREADED WATERPROOF CONNECTION.
PEDALSENSE : FREE RIDE MODE (NO POWER), TWO LEVELS OF PEDAL ASSIST WITH THROTTLE OVERRIDE, AND THROTTLE ONLY MODE.
THROTTLE : 10 MPH WITH MOTOR ASSISTANCE ONLY. PEDAL ASSIST: 7 MPH WITH MOTOR ASSISTANCE ONLY.
INTERNAL GEARED HUB : SHIMANO NEXUS 3 SPEED REAR HUB; ALUMINUM HUB SHELL; CENTER LOCK ROTOR MOUNT SYSTEM; GEAR 1 RATIO: 0.733, GEAR 2 RATIO: 1.000, GEAR 3 RATIO 1.360, 186% TOTAL GEAR RATIO.
PADS : FRONT: SHIMANO RESIN WITH STEEL BACKING PLATE; OE QUALITY FOR NO-COMPROMISE DISC BRAKE PERFORMANCE; REAR: AVID ORGANIC WITH STEEL BACKING PLATE; OE QUALITY FOR NO-COMPROMISE DISC BRAKE PERFORMANCE.
CARGO BUCKET : CUSTOM COMPOSITE CARGO BUCKET; BUCKET OPENING DIMENSIONS: 20” W X 13” L; OVERALL WIDTH: 30”.
TOOLKIT : CUSTOM PEDEGO TOOL KIT: 6” ADJUSTABLE WRENCH (UP TO 15MM), 12/13G SPOKE WRENCH, T25 TORX WRENCH, 6MM HEX WRENCH, 5MM HEX WRENCH WITH #2 PHILLIPS SCREWDRIVER, 4MM HEX WRENCH
