68MM X 127.5MM SQUARE TAPER SPINDLE WITH SEALED CARTRIDGE BEARINGS; STEEL CUPS AND BODY.
Stand
BLACK HEAVY-DUTY ALUMINUM ALLOY DOUBLE-LEG KICKSTAND; COMPOSITE FEET.
Motor Details
SILVER 48V BRUSHLESS GEARED REAR HUB MOTOR; 500 WATT NOMINAL POWER RATING; 45NM TORQUE; QUICK DISCONNECT WITH WATERPROOF CONNECTION.
Display
3.5” BACKLIT LCD SCREEN; 4 BUTTONS TO CONTROL ELECTRONICS, TOGGLE INFO DISPLAYED, AND CUSTOMIZE SETTINGS; USB CHARGING PORT; WATERPROOF THREADED CONNECTION; CUSTOM PEDALSENSE SOFTWARE.
Electricals
Battery
48 VOLT 13 OR 17 AMP HOUR WITH PREMIUM LITHIUM-ION 18650 CELLS; INTEGRATED FOLDING HANDLE FOR EASY REMOVAL; EXTERNAL LED STATE OF CHARGE INDICATOR.
WEIGHT : 48V/17AH: 12.2 LB; 48V/13AH: 11.8 LB.
Charger
3 AMP SMART CHARGER WITH INTERNAL FAN AND CHARGE INDICATOR LIGHT.
Controller
48 VOLT 18 AMP SINE WAVE CONTROLLER WITH CUSTOM PEDALSENSE® SOFTWARE AND WATERPROOF CONNECTIONS.
Head Lamp
FORK LEG-MOUNTED LED WITH ADJUSTABLE MOUNT 40 LUX (200 LUMENS)
Tail Lamp
FRAME-MOUNTED LED
Brakes
Front Brake
AVID BB7 MOUNTAIN MECHANICAL DISC BRAKES
Rear Brake
AVID BB7 MOUNTAIN MECHANICAL DISC BRAKES
Brake Lever
TEKTRO ERGONOMIC LEVER WITH RUBBER FINGER PADDING; INTEGRATED LEFT-HAND BELL; INTEGRATED MOTOR CUT-OFF SWITCH FOR MAXIMUM SAFETY.
Chassis and Suspension
Frame
6061-T6 ALUMINUM ALLOY; REMOVABLE FRONT CARGO TRAY; INTEGRATED REINFORCED REAR RACK; MODULAR REAR ATTACHMENTS FOR CARGO AND PASSENGERS; INTERNAL CABLE AND WIRE ROUTING.
Tyres
Wheels / Rim
24” EXTRA STRENGTH DOUBLE WALL LIGHTWEIGHT ALUMINUM ALLOY; 12G X 36 HOLE.
