INTERMEDIATE COMFORT SADDLE WITH SOFT FOAM; CENTER CHANNEL CUTOUT; DUAL SIDE FACING PEDEGO LOGO; 275MM L X 185MM W.
Headset
BLACK ZERO-STACK SEMI-INTEGRATED 1 ⅛” THREADLESS; ZS44/28.6-26TPI | ZS44/30.
Spoke
BLACK HEAVY-DUTY 13 GAUGE STAINLESS STEEL SPOKES WITH BRASS NIPPLES.
Bottom Bracket
68MM X 116MM SQUARE TAPER SPINDLE WITH SEALED CARTRIDGE BEARINGS; STEEL CUPS AND BODY.
Stand
BLACK ALUMINUM ALLOY CENTER KICKSTAND; ADJUSTABLE LENGTH COMPOSITE FOOT.
Motor Details
BLACK 36V BRUSHLESS GEARED FRONT HUB MOTOR; 250 WATT NOMINAL POWER RATING; 30NM TORQUE; QUICK DISCONNECT CABLE WITH WATERPROOF CONNECTION.
Display
3.5” BACKLIT LCD SCREEN; 4 BUTTONS TO CONTROL ELECTRONICS, TOGGLE INFO DISPLAYED, AND CUSTOMIZE SETTINGS; USB CHARGING PORT; WATERPROOF THREADED CONNECTION; CUSTOM PEDALSENSE SOFTWARE.
Electricals
Battery
36 VOLT 10 OR 15 AMP HOUR WITH PREMIUM LITHIUM-ION 18650 CELLS.
Charger
3 AMP SMART CHARGER WITH INTERNAL FAN AND CHARGE INDICATOR LIGHT.
Controller
36 VOLT 15 AMP SINE WAVE CONTROLLER WITH CUSTOM PEDALSENSE® SOFTWARE AND WATERPROOF CONNECTIONS.
Head Lamp
LED WITH ADJUSTABLE MOUNT 40 LUX (200 LUMENS)
Tail Lamp
LED BUILT INTO BATTERY
Brakes
Front Brake
AVID BB7S MOUNTAIN MECHANICAL DISC BRAKES
Rear Brake
AVID BB7S MOUNTAIN MECHANICAL DISC BRAKES
Brake Lever
TEKTRO ERGONOMIC LEVER WITH RUBBER FINGER PADDING; INTEGRATED LEFT-HAND BELL; INTEGRATED MOTOR CUT-OFF SWITCH FOR MAXIMUM SAFETY.
Chassis and Suspension
Frame
6061-T6 ALUMINUM ALLOY; INTEGRATED REINFORCED REAR RACK FOR BATTERY AND STORAGE; INTERNAL / EXTERNAL CABLE AND WIRE ROUTING.
Tyres
Wheels / Rim
20” ALEX DM24 E-BIKE RATED DOUBLE WALL; LIGHTWEIGHT ALUMINUM ALLOY; 13G X 36 HOLE.
Front Tyre
SCHWALBE BIG APPLE 20” X 2.0” WITH K-GUARD KEVLAR FLAT PROTECTION; SCHRADER VALVE.
Rear Tyre
SCHWALBE BIG APPLE 20” X 2.0” WITH K-GUARD KEVLAR FLAT PROTECTION; SCHRADER VALVE.
Dimensions
Length
21mm
Additional Details
THROTTLE : TWIST AND GO THROTTLE WITH THREADED WATERPROOF CONNECTION.
PEDALSENSE : FREE RIDE MODE (NO POWER), FIVE LEVELS OF PEDAL ASSIST WITH THROTTLE OVERRIDE, AND THROTTLE ONLY MODE.
INTERNAL GEARED HUB : SHIMANO NEXUS 3 SPEED REAR HUB; ALUMINUM HUB SHELL; CENTER LOCK ROTOR MOUNT SYSTEM; GEAR 1 RATIO: 0.733, GEAR 2 RATIO: 1.000, GEAR 3 RATIO: 1.360, 186% TOTAL GEAR RATIO.
REAR SPROCKET : GATES 22T SUREFIT 3-LOBE STAINLESS STEEL SPROCKET.
BELT : GATES CDN 115T BELT; ENGINEERED POLYMER / CARBON TENSILE CORD.
PADS : AVID ORGANIC WITH STEEL BACKING PLATE; OE QUALITY FOR NO-COMPROMISE DISC BRAKE PERFORMANCE.
TOOLKIT : CUSTOM PEDEGO TOOL KIT: 6” ADJUSTABLE WRENCH (UP TO 15MM), 12/13G SPOKE WRENCH, T25 TORX WRENCH, 6MM HEX WRENCH, 5MM HEX WRENCH WITH #2 PHILLIPS SCREWDRIVER, 4MM HEX WRENCH.
