24” OR 26” RIGID CHROMOLY STEEL; 1 ⅛” THREADED STEERER TUBE; DISC BRAKE AND FENDER MOUNTS.
Seatpost
SILVER 27.2MM X 300MM RIGID SEATPOST.
Grip
STANDARD : BLACK WEAR RESISTANT PEDEGO GRIPS
OPTIONAL : PEDEGO SYNTHETIC LEATHER GRIP WITH HAND STITCHING AND FOAM PADDING; COLOR MATCHED BALLOON PACKAGE.
68MM X 127.5MM SQUARE TAPER SPINDLE WITH SEALED CARTRIDGE BEARINGS; STEEL CUPS AND BODY.
Stand
SILVER ALUMINUM ALLOY CENTER KICKSTAND; ADJUSTABLE LENGTH COMPOSITE FOOT.
Motor Details
SILVER 36V BRUSHLESS GEARED REAR HUB MOTOR; 350 WATT NOMINAL POWER RATING; 35NM TORQUE; QUICK DISCONNECT CABLE WITH WATERPROOF CONNECTION.
Display
2.5” BACKLIT LCD SCREEN; 3 BUTTONS TO CONTROL ELECTRONICS, TOGGLE INFO DISPLAYED, AND CUSTOMIZE SETTINGS; USB CHARGING PORT; WATERPROOF THREADED CONNECTION; CUSTOM PEDALSENSE SOFTWARE.
Electricals
Battery
36 VOLT 10 OR 15 AMP HOUR WITH PREMIUM LITHIUM ION 18650 CELLS.
Weight : 36V/15AH: 7.6 LB; 36V/10AH: 7 LB.
Charger
3 AMP SMART CHARGER WITH INTERNAL FAN AND CHARGE INDICATOR LIGHT.
Controller
36 VOLT 18 AMP SINE WAVE CONTROLLER WITH CUSTOM PEDALSENSE SOFTWARE AND WATERPROOF CONNECTIONS.
Tail Lamp
LED BUILT INTO BATTERY; POWERED AND CONTROLLED BY MAIN BATTERY VIA PUSH BUTTON
Brakes
Front Brake
SHIMANO BR-M375 MECHANICAL DISC
Rear Brake
SHIMANO BR-M375 MECHANICAL DISC
Brake Lever
TEKTRO ERGONOMIC LEVER WITH RUBBER FINGER PADDING; INTEGRATED LEFT HAND BELL; INTEGRATED MOTOR CUT OFF SWITCH FOR MAXIMUM SAFETY.
Chassis and Suspension
Frame
6061-T6 ALUMINUM ALLOY; INTEGRATED REINFORCED REAR RACK FOR BATTERY AND STORAGE; INTERNAL CABLE AND WIRE ROUTING.
Tyres
Wheels / Rim
24” OR 26” EXTRA STRENGTH DOUBLE WALL LIGHTWEIGHT ALUMINUM ALLOY; 12G X 36 HOLE.
Front Tyre
KENDA WHITE WALL 24” X 2.125” OR 26” X 2.3”;
Rear Tyre
KENDA WHITE WALL 24” X 2.125” OR 26” X 2.3”
Additional Details
THROTTLE : TWIST AND GO THROTTLE WITH THREADED WATERPROOF CONNECTION.
PEDALSENSE : FREE RIDE MODE (NO POWER), FIVE LEVELS OF PEDAL ASSIST WITH THROTTLE OVERRIDE, AND THROTTLE ONLY MODE.
BRAKE PADS : SHIMANO RESIN WITH STEEL BACKING PLATE; OE QUALITY FOR NO-COMPROMISE DISC BRAKE PERFORMANCE.
TOOL KIT: CUSTOM PEDEGO TOOL KIT: 6” ADJUSTABLE WRENCH (UP TO 15MM), 12/13G SPOKE WRENCH, T25 TORX WRENCH, 6MM HEX WRENCH, 5MM HEX WRENCH WITH #2 PHILLIPS SCREWDRIVER, 4MM HEX WRENCH.
