SHIMANO SLX M670 10 SPEED; DYNA-SYS WITH OPTICAL GEAR DISPLAY; MODEL NO: SL-M670-R.
Saddle
EXTRA WIDE CRUISER STYLE SADDLE WITH SOFT FOAM; REAR FACING PEDEGO LOGO; 265MM L X 265MM W.
Headset
ZERO STACK SEMI-INTEGRATED 1 ⅛” THREADED; ZS44/28.6-26TPI | ZS44/30
Derailleur : Rear
SHIMANO SLX M7000 10 SPEED; INTEGRATED CLUTCH FOR MAXIMUM CHAIN RETENTION; RIDER TUNED FOR SHARP AND SILKY SHIFTS; MODEL NO: RD-M7000-10-SGS.
Spoke
BLACK 12 GAUGE HEAVY DUTY STAINLESS STEEL SPOKES WITH BRASS NIPPLES.
Cassette
SHIMANO DEORE M6000 10 SPEED HYPERGLIDE 11-36T; PRECISE AND CONSISTENT SHIFTING PERFORMANCE; MODEL NO: CS-HG50-10.
Bottom Bracket
68MM X 127.5MM SQUARE TAPER SPINDLE WITH SEALED CARTRIDGE BEARINGS; INTEGRATED TORQUE SENSOR.
Stand
BLACK ALUMINUM ALLOY CENTER KICKSTAND; ADJUSTABLE LENGTH COMPOSITE FOOT.
Motor Details
BLACK 52V BRUSHLESS GEARED REAR HUB MOTOR; 749 WATT NOMINAL POWER RATING; 60NM TORQUE; QUICK DISCONNECT CABLE WITH WATERPROOF CONNECTION.
Display
3.5” BACKLIT LCD SCREEN WITH CANBUS COMMUNICATION; 4 BUTTONS TO CONTROL ELECTRONICS, TOGGLE INFO DISPLAYED, AND CUSTOMIZE SETTINGS; USB CHARGING PORT; WATERPROOF THREADED CONNECTION; CUSTOM PEDALSENSE SOFTWARE
Electricals
Battery
52 VOLT 17.5 OR 10.5 AMP HOUR WITH PREMIUM LITHIUM ION 18650 CELLS; SMART BIKE TECHNOLOGY WITH CANBUS COMMUNICATION; AUTO SLEEP FUNCTION.
WEIGHT : 52V/15AH: 9.2 LB; 52V/10AH: 8.8 LB.
52 VOLT 22 AMP SINE WAVE CONTROLLER WITH CUSTOM PEDALSENSE® SOFTWARE AND WATERPROOF CONNECTIONS.
Head Lamp
LED WITH ADJUSTABLE MOUNT 60 LUX
Tail Lamp
LED
Brakes
Front Brake
TEKTRO DORADO; 2 PISTON HYDRAULIC DISC BRAKE WITH FORGED ALUMINUM BODY, ADJUSTABLE HOSE ANGLE; TEKTRO NON-CORROSIVE MINERAL OIL.
Rear Brake
TEKTRO DORADO; 2 PISTON HYDRAULIC DISC BRAKE WITH FORGED ALUMINUM BODY, ADJUSTABLE HOSE ANGLE; TEKTRO NON-CORROSIVE MINERAL OIL.
Brake Lever
TEKTRO DORADO FORGED ALUMINUM LEVER; 4 FINGER BLADE WITH BALL END; VISUALIZED RESERVOIR; INTEGRATED MOTOR CUTOFF SWITCH FOR MAXIMUM SAFETY.
Chassis and Suspension
Frame
6061-T6 ALUMINUM ALLOY; INTEGRATED REINFORCED REAR RACK FOR BATTERY AND STORAGE; INTERNAL CABLE AND WIRE ROUTING.
Tyres
Wheels / Rim
24” OR 26” ALUMINUM ALLOY DOUBLE WALL RIMS; 24.7MM INTERNAL WIDTH; PINNED JOINT; 3D ANGLE DRILLED SPOKE HOLES; 12G X 36 HOLE.
Front Tyre
SCHWALBE FAT FRANK 28” X 2.0” WITH K-GUARD KEVLAR FLAT PROTECTION OR SCHWALBE BIG APPLE 26” X 2.0” WITH RACEGUARD FLAT PROTECTION; SLIME INNER TUBE SEALANT; SCHRADER VALVE.
Rear Tyre
SCHWALBE FAT FRANK 28” X 2.0” WITH K-GUARD KEVLAR FLAT PROTECTION OR SCHWALBE BIG APPLE 26” X 2.0” WITH RACEGUARD FLAT PROTECTION; SLIME INNER TUBE SEALANT; SCHRADER VALVE.
Additional Details
THROTTLE : CUSTOM PEDEGO TWIST AND GO THROTTLE WITH COLOR LED ASSIST INDICATOR FOR MAXIMUM SAFETY; THREADED WATERPROOF CONNECTION.
PEDALSENSE : FREE RIDE MODE (NO POWER), FIVE LEVELS OF PEDAL ASSIST WITH THROTTLE OVERRIDE AND TORQUE OR CADENCE MODE, THROTTLE ONLY MODE.
PADS : CERAMIC MATERIAL WITH STEEL BACKING PLATE; OFFER SAFETY TOGETHER WITH EXCELLENT PERFORMANCE IN ALL SITUATIONS.
TOOLKIT : CUSTOM PEDEGO TOOL KIT: 6” ADJUSTABLE WRENCH (UP TO 15MM), 12/13G SPOKE WRENCH, T25 TORX WRENCH, 6MM HEX WRENCH, 5MM HEX WRENCH WITH #2 PHILLIPS SCREWDRIVER, 4MM HEX WRENCH.
FENDERS : MATTE BLACK STEEL FULL LENGTH FENDERS WITH INTEGRATED MUD FLAPS; STAINLESS STEEL STAYS.
