PROPRIETARY MID-DRIVE MOTOR INTEGRATION; SQUARE TAPER SPINDLE WITH INTEGRATED TORQUE SENSOR.
Stand
BLACK ALUMINUM ALLOY CENTER KICKSTAND; ADJUSTABLE LENGTH COMPOSITE FOOT.
Motor Details
BLACK 48V BRUSHLESS GEARED MID-DRIVE MOTOR WITH INTEGRATED TORQUE SENSOR; 500 WATT NOMINAL POWER RATING; 95NM TORQUE.
Display
3.5” BACKLIT LCD SCREEN; 4 BUTTONS TO CONTROL ELECTRONICS, TOGGLE INFO DISPLAYED, AND CUSTOMIZE SETTINGS; USB CHARGING PORT; WATERPROOF THREADED CONNECTION; CUSTOM PEDALSENSE SOFTWARE.
Electricals
Battery
48 VOLT 10 OR 15 AMP-HOUR LITHIUM-ION WITH NAME BRAND 18650 CELLS.
WEIGHT : 48V/15AH: 9.2 LB; 48V/10AH: 8.8 LB.
Charger
3 AMP SMART CHARGER WITH INTERNAL FAN AND CHARGE INDICATOR LIGHT.
Controller
48 VOLT 18 AMP SINE WAVE CONTROLLER WITH CUSTOM PEDALSENSE SOFTWARE AND WATERPROOF CONNECTIONS.
Head Lamp
LED WITH ADJUSTABLE MOUNT 40 LUX (200 LUMENS)
Tail Lamp
LED
Brakes
Front Brake
STAR UNION 2 PISTON FORGED ALUMINUM HYDRAULIC DISC BRAKE; MINERAL OIL BRAKE FLUID.
Rear Brake
STAR UNION 2 PISTON FORGED ALUMINUM HYDRAULIC DISC BRAKE; MINERAL OIL BRAKE FLUID.
Brake Lever
STAR UNION 3 FINGER LEVER; CAST ALUMINUM WITH MOTOR CUTOFF SWITCH FOR MAXIMUM SAFETY.
Chassis and Suspension
Frame
6061-T6 ALUMINUM ALLOY WITH MID-DRIVE MOTOR MOUNT; INTEGRATED REINFORCED REAR RACK FOR BATTERY AND STORAGE; INTERNAL CABLE AND WIRE ROUTING.
Tyres
Wheels / Rim
26” OR 28” EXTRA STRENGTH DOUBLE WALL LIGHTWEIGHT ALUMINUM ALLOY; 12G X 36 HOLE.
Front Tyre
SCHWALBE FAT FRANK 28” X 2.0” WITH K-GUARD KEVLAR FLAT PROTECTION OR SCHWALBE BIG APPLE 26” X 2.0” WITH RACEGUARD FLAT PROTECTION; SLIME INNER TUBE SEALANT; SCHRADER VALVE.
Rear Tyre
SCHWALBE FAT FRANK 28” X 2.0” WITH K-GUARD KEVLAR FLAT PROTECTION OR SCHWALBE BIG APPLE 26” X 2.0” WITH RACEGUARD FLAT PROTECTION; SLIME INNER TUBE SEALANT; SCHRADER VALVE.
Additional Details
THROTTLE : TWIST AND GO THROTTLE WITH THREADED WATERPROOF CONNECTION.
PEDALSENSE : FREE RIDE MODE (NO POWER), FIVE LEVELS OF PEDAL ASSIST WITH THROTTLE OVERRIDE, AND THROTTLE ONLY MODE.
GEAR SENSOR : CUSTOM SENSOR MOMENTARILY CUTS MOTOR POWER DURING GEAR SHIFTS TO MINIMIZE DRIVETRAIN WEAR.
PADS : ORGANIC MATERIAL WITH STEEL BACKING PLATE; OFFER SAFETY TOGETHER WITH EXCELLENT PERFORMANCE IN ALL SITUATIONS.
TOOL KIT : CUSTOM PEDEGO TOOL KIT: 6” ADJUSTABLE WRENCH (UP TO 15MM), 12/13G SPOKE WRENCH, T25 TORX WRENCH, 6MM HEX WRENCH, 5MM HEX WRENCH WITH #2 PHILLIPS SCREWDRIVER, 4MM HEX WRENCH.
FENDERS : BLACK / COLOR-MATCHED STEEL FULL-LENGTH FENDERS WITH INTEGRATED MUD FLAPS; STAINLESS STEEL STAYS.
