68MM X 137MM SQUARE TAPER SPINDLE WITH SEALED CARTRIDGE BEARINGS; STEEL CUPS AND BODY.
Stand
BLACK ALUMINUM ALLOY CENTER KICKSTAND; ADJUSTABLE LENGTH COMPOSITE FOOT.
Motor Details
SILVER 36V BRUSHLESS GEARED REAR HUB MOTOR; 350 WATT NOMINAL POWER RATING; 35NM TORQUE; QUICK DISCONNECT CABLE WITH WATERPROOF CONNECTION.
Display
2.5” BACKLIT LCD SCREEN; 3 BUTTONS TO CONTROL ELECTRONICS, TOGGLE INFO DISPLAYED, AND CUSTOMIZE SETTINGS; USB CHARGING PORT; WATERPROOF THREADED CONNECTION; CUSTOM PEDALSENSE SOFTWARE.
Electricals
Battery
36 VOLT 10 OR 15 AMP HOUR WITH PREMIUM LITHIUM-ION 18650 CELLS.
WEIGHT : 36V/15AH: 7.6 LB; 36V/10AH: 7 LB.
Charger
3 AMP SMART CHARGER WITH INTERNAL FAN AND CHARGE INDICATOR LIGHT.
Controller
36 VOLT 18 AMP SINE WAVE CONTROLLER WITH CUSTOM PEDALSENSE® SOFTWARE AND WATERPROOF CONNECTIONS.
Tail Lamp
LED BUILT INTO BATTERY
Brakes
Front Brake
SHIMANO BR-M375 MECHANICAL DISC BRAKES
Rear Brake
SHIMANO BR-M375 MECHANICAL DISC BRAKES
Brake Lever
TEKTRO ERGONOMIC LEVER WITH RUBBER FINGER PADDING; INTEGRATED LEFT-HAND BELL; INTEGRATED MOTOR CUT-OFF SWITCH FOR MAXIMUM SAFETY.
Chassis and Suspension
Frame
6061-T6 ALUMINUM ALLOY; INTEGRATED REINFORCED REAR RACK FOR BATTERY AND STORAGE; INTERNAL CABLE AND WIRE ROUTING.
Tyres
Wheels / Rim
EXTRA STRENGTH DOUBLE WALL LIGHTWEIGHT ALUMINUM ALLOY; 12G X 36 HOLE.
Front Tyre
KENDA BLACK WALL 26” X 1.95” OR 28” X 1.75 ”; PUNCTURE RESISTANT CASING; REFLECTIVE SIDEWALL; SLIME INNER TUBE SEALANT; SCHRADER VALVE.
Rear Tyre
KENDA BLACK WALL 26” X 1.95” OR 28” X 1.75 ”; PUNCTURE RESISTANT CASING; REFLECTIVE SIDEWALL; SLIME INNER TUBE SEALANT; SCHRADER VALVE.
Additional Details
THROTTLE : TWIST AND GO THROTTLE WITH THREADED WATERPROOF CONNECTION.
PEDALSENSE : FREE RIDE MODE (NO POWER), FIVE LEVELS OF PEDAL ASSIST WITH THROTTLE OVERRIDE, AND THROTTLE ONLY MODE.
PADS : SHIMANO RESIN WITH STEEL BACKING PLATE; OE QUALITY FOR NO-COMPROMISE DISC BRAKE PERFORMANCE.
TOOL KIT : CUSTOM PEDEGO TOOL KIT: 6” ADJUSTABLE WRENCH (UP TO 15MM), 12/13G SPOKE WRENCH, T25 TORX WRENCH, 6MM HEX WRENCH, 5MM HEX WRENCH WITH #2 PHILLIPS SCREWDRIVER, 4MM HEX WRENCH.
FENDERS : OPTIONAL UPGRADE: COLOR-MATCHED STEEL FULL-LENGTH FENDERS WITH INTEGRATED. MUDFLAPS; STAINLESS STEEL STAYS.
