Integrated ignition - injection system MVICS 2.0 (Motor & Vehicle Integrated Control System) with six injectors.
Cooling System
Cooling with separated liquid and oil radiators.
Maximum Power
140 PS @ 12300 RPM
Maximum Torque
87 NM @ 10100 RPM
Transmission
Cassette style; six speed, constant mesh
Gear Shift Pattern
1-N-2-3-4-5-6
Top Speed
244kmph
Electricals
Battery
12 V - 8.6 Ah
Brakes
Front Brake
Double floating disc with Ø 320 mm (Ø 12.6 in.) diameter, with steel braking disc and flange
Rear Brake
Single steel disc with Ø 220 mm (Ø 8.66 in.)
ABS System
Bosch 9 Plus with RLM (Rear wheel Lift-up Mitigation)
Chassis and Suspension
Frame
ALS Steel tubular trellis
Front Suspension
Marzocchi “UPSIDE DOWN” telescopic hydraulic fork in DLC treated aluminium, with anodized fork legs and having rebound-compression damping and spring preload external and separate adjustment
Rear Suspension
Progressive Sachs, single shock absorber with rebound and compression damping and spring preload adjustment
Tyres
Wheels / Rim
Front: aluminium alloy spokes 3.50” x 17”
Rear: aluminium alloy spokes 6.00” x 17”
Front Tyre
120/70 - ZR 17 M/C (58 W)
Rear Tyre
200/50 - ZR 17 M/C (75 W)
Dimensions
Length
2035mm
Width
935mm
Seat Height
845 mm
Wheelbase
1400 mm
Kerb Weight
168 kg
Ground Clearance
135 mm
Fuel Tank Capacity
16.5 litres
Additional Details
Primary drive : 22/41
Gear ratio :
First gear: 13/37
Second gear: 16/34
Third gear: 18/32
Fourth gear: 19/30
Fifth gear: 21/30
Sixth gear: 22/29
Final drive ratio : 16/41
Electronic quick-shift : MV EAS 2.1 (Electronically Assisted Shift up & down)
Environmental Standard : Euro 4
Combined fuel consumption : 6.7 l/100 km
CO2 Emissions : 163 g/km
