Integrated ignition - injection system MVICS 2.0 (Motor & Vehicle Integrated Control System) with six injectors.
Cooling System
Cooling with separeted liquid and oil radiators
Maximum Power
140 PS @ 12.300 RPM
Maximum Torque
87 NM @ 10.100 RPM
Transmission
Cassette style; six speed, constant mesh
Gear Shift Pattern
1-N-2-3-4--5-6
Electricals
Battery
12 V - 8.5 Ah
Brakes
Front Brake
Double floating disc with Ø 320 mm (Ø 12.6 in.) diameter, with steel braking disc and flange
Rear Brake
Single steel disc with Ø 220 mm (Ø 8.66 in.) dia.
ABS System
Bosch 9 Plus with RLM (Rear wheel Lift-up Mitigation)
Chassis and Suspension
Frame
ALS Steel tubular trellis
Front Suspension
Marzocchi “UPSIDE DOWN” aluminium telescopic hydraulic fork with DLC treatment , with anodized fork legs and having rebound-compression damping and spring preload external and separate adjustment
Rear Suspension
Progressive Sachs, single shock absorber with rebound and compression damping and spring preload adjustment
Tyres
Wheels / Rim
Front: Material/size Aluminium alloy 3.50 ” x 17 ”
Rear: Material/size Aluminium alloy 5.50 ” x 17 ”
Front Tyre
120/70 - ZR 17 M/C (58 W)
Rear Tyre
180/55 - ZR 17 M/C (73 W
Dimensions
Length
2045mm
Width
875mm
Seat Height
830 mm
Wheelbase
1400 mm
Kerb Weight
175 kg
Ground Clearance
135 mm
Fuel Tank Capacity
16.5 litres
Additional Details
Engine management system : Engine control unit Eldor EM2.0, throttle body full ride by wire Mikuni, pencil-coil with ion-sensing technology, control of detonation and misfire. Torque control with four maps, Traction Control with eight levels of intervention with lean angle sensor.
Electronic quick-shift : MV EAS 2.1 (Electronically Assisted Shift up & down
Primary drive 22/41
Gear ratio : First gear: 13/37
Second gear: 16/34
Third gear: 18/32
Fourth gear: 19/30
Fifth gear: 21/30
Sixth gear: 22/29
Final drive ratio : 16/41
Trail : 103.5 mm
Front Fork : 43 mm (1.69 in.)
Fork travel : 125 mm (4.92 in.)
Rear Wheel travel : 124 mm (4.88 in.)
Parking brake : Integrated in the rear hydraulic brake system
Environmental Standard : Euro 4
Combined fuel consumption : 6.7 l/100 km
CO2 Emissions : 163 g/km
