Three cylinder, 4 stroke, 12 valve “D.O.H.C” with mechanical chain tensioner
Engine Starting
Electric
Bore x Stroke
79.0mm x 54.3mm
Compression Ratio
12.3:1
Clutch
Multi-disk wet clutch with hydraulic actuation and back torque limiting device
Fuel System
Fuel Injection
Ignition
Integrated ignition - injection system MVICS (Motor & Vehicle Integrated Control System)with three injectors.
Cooling System
Cooling with separeted liquid and oil radiators
Maximum Power
110 PS @ 11500 RPM
Maximum Torque
83 NM @ 7600 RPM
Transmission
Cassette style; six speed, constant mesh
Gear Shift Pattern
1-N-2-3-4-5-6
Top Speed
237kmph
Electricals
Battery
12 V - 8.5 Ah
Brakes
Front Brake
Double floating disc with Ø 320 mm (Ø 12.6 in.) diameter, with steel braking disc and flange
Rear Brake
Single steel disc with Ø 220 mm (Ø 8.66 in.)
ABS System
Bosch 9 Plus with RLM (Rear wheel Lift-up Mitigation)
Chassis and Suspension
Frame
ALS Steel tubular trellis
Front Suspension
Marzocchi “UPSIDE DOWN” telescopic hydraulic fork with rebound-compression damping and spring preload external and separate adjustment
Rear Suspension
Progressive Sachs, single shock absorber with rebound and compression damping and spring preload adjustment
Tyres
Wheels / Rim
Front : Aluminium alloy 3.50 ” x 17 ”
Rear: Aluminium alloy 5.50 ” x 17 ”
Front Tyre
120/70 - ZR 17 M/C (58 W)
Rear Tyre
180/55 - ZR 17 M/C (73 W)
Dimensions
Length
1400mm
Width
875mm
Seat Height
830 mm
Wheelbase
1400 mm
Kerb Weight
175 kg
Ground Clearance
135 mm
Fuel Tank Capacity
16.5 litres
Additional Details
Electronic quick-shift : MV EAS 2.1 (Electronically Assisted Shift up & down)
Primary drive 22/41
Gear ratio :
First gear: 13/37
Second gear: 16/35
Third gear: 18/32
Fourth gear: 20/30
Fifth gear: 22/29
Sixth gear: 21/25
Final drive ratio : 16/41
Voltage : 12 V
Alternator : 350 W at 5000 r.p.m.
Trail : 1035 mm
Environmental Standard : Euro 4
Combined fuel consumption : 5.6 l/100 km - 5.4 l/100 km(35 kW)
CO2 Emissions : 128 g/km - 126 g/km (35 kW)
