Marin Mini-Riser, 6061 Double Butted Aluminum, 780 mm Width, 28 mm rise, 5º Up, 9º Back
Fork
RockShox Recon RL 27.5", 130 mm Travel, Solo Air, Compression and Rebound Adjustment, Alloy Tapered Steerer, Fast Black Uppers, 110 x 15 mm Boost Spacing, Maxle Stealth, 46 mm Offset
Seatpost
Marin Alloy, 30.9 mm
Grip
Marin MTN, Closed End
Crankset
Marin Forged Alloy 1 x 10, Hollow Spindle, Steel Narrow-Wide 32T Chainring, 76 mm BCD
Pedals
Marin Plastic Stock Pedals
Chain
KMC X10
Shifters
Shift Lever : Shimano Deore 1x10-Speed
Saddle
Marin Speed Concept
Headset
FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
Derailleur : Rear
Shimano Deore Shadow Plus Direct Mount 10-Speed
Hub : Front
Forged Alloy, 148 x 12 mm, Quad Sealed Bearings, 6-Bolt Disc, 32H, Standard Feehub Body
Hub : Rear
Forged Alloy, 110 x 15 mm, 6-Bolt Disc, 32H
Spoke
14 g Black Stainless Steel
Cassette
SunRace 10-Speed, 11-46T
Brakes
Front Brake
Shimano BR-MT201 Hydraulic Disc, 180 mm Rotor
Rear Brake
Shimano BR-MT201 Hydraulic Disc, 160 mm Rotor
Brake Lever
Shimano BR-MT201 Hydraulic Disc
Chassis and Suspension
Frame
Series 3 6061 Aluminum Frame, 27.5” Wheels, 120 mm Travel, MultiTrac Suspension Platform, 141 Boost Spacing (upgradable to 148 x 12), 73 mm Threaded BB w/ ISCG05 Tabs
Vee Tire, Crown Gem 27.5 x 2.3", Dual Control Compound, Folding Bead, Tubeless Compatible
Rear Tyre
Vee Tire, Crown Gem 27.5 x 2.3", Dual Control Compound, Folding Bead, Tubeless Compatible
Additional Details
Shock : X-Fusion O2 Pro R, Custom Tune, 210 x 50 mm, 25 mm x M8 Hardware Top and Bottom
Bottom Bracket : External Sealed Cartridge Bearings
Extras : Closed 9-12 Thru Axle QR System
