Wet multi-disc manual clutch and hydraulic clutch actuation
Fuel System
DFI® with 44mm Keihin throttle body
Ignition
Digital CDI with 3 Coupler Options
Cooling System
Liquid-cooled
Transmission
5-speed, return shift
Gear Shift Pattern
1-N-2-3-4-5
Drivetrain
Final Drive : Chain
Brakes
Front Brake
Single semi-floating 270mm Braking® petal disc with dual-piston caliper
Rear Brake
Single 240mm Braking® petal disc with single-piston caliper
Chassis and Suspension
Frame
Aluminum perimeter
Front Suspension
49mm inverted telescopic coil-spring fork with 16-way compression damping and 16-way rebound damping/12.0 in
Rear Suspension
Uni-Trak® gas charged shock with piggyback reservoir with dual-range (4 turns stepless high speed/19-way low-speed) compression damping, 22-way rebound damping and adjustable preload/12.1 in
Tyres
Wheels / Rim
Spoke
Front Tyre
80/100-21
Rear Tyre
120/90-18
Dimensions
Length
2184mm
Width
820mm
Height
1265mm
Seat Height
950 mm
Wheelbase
1486 mm
Kerb Weight
107/112 kg
Ground Clearance
335 mm
Fuel Tank Capacity
7 litres
Additional Details
Rake/Trail : 27.6°/4.7 in
Vehicle Warranty
Not Available
Kawasaki Protection Plus (optional) : Not Available
