43 mm inverted Balance Free Front Fork with external compression chamber, compression and rebound damping and spring preload adjustability, and top-out springs
Wheel travel front : 120 mm
Rear Suspension
Horizontal Back-link with BFRC lite gas-charged shock, piggyback reservoir, compression and rebound damping and spring preload adjustability, and top-out spring
Wheel travel rear : 115 mm
Tyres
Wheels / Rim
Alloy
Front Tyre
120/70ZR17M/C (58W)
Rear Tyre
190/55ZR17M/C (75W)
Dimensions
Length
2085mm
Width
750mm
Height
1185mm
Seat Height
835 mm
Wheelbase
1450 mm
Kerb Weight
207 kg
Ground Clearance
135 mm
Fuel Tank Capacity
17 litres
Additional Details
- Valve system : DOHC, 16 valves
- Fuel consumption : 6 l/100 km
- CO2 emission : 140 g/km
- Primary Reduction Ratio : 1.681 (79/47)
- Gear Ratios 1st2.600 (39/15)
- Gear Ratios 2nd2.158 (41/19)
- Gear Ratios 3rd1.882 (32/17)
- Gear Ratios 4th1.650 (33/20)
- Gear Ratios 5th1.476 (31/21)
- Gear Ratios 6th1.304 (30/23)
- Final reduction ratio: 2.412 (41/17)
- Trail : 105 mm
- Steering angle, left / right : 27° / 27°
