| Vehicle Type | ATV |
| Fuel | Petrol |
| Engine Displacement | 749.00 cc |
| Engine Details | 4-stroke, V-twin, SOHC, liquid-cooled |
| Engine Starting | Electric |
| Bore x Stroke | 85mm x 66mm |
| Compression Ratio | 9.3:1 |
| Fuel System | DFI with two 36 mm throttle bodies |
| Ignition | Digital DC-CDI |
| Cooling System | Liquid-cooled |
| Transmission | Automatic CVT (H,L,N,R) |
| Brakes | |
|---|---|
| Front Brake | Dual hydraulic 176 mm discs with 2-piston calipers |
| Rear Brake | Sealed, oil-bathed, multi-disc with independent park brake |
| Chassis and Suspension | |
|---|---|
| Frame | Double-cradle, high-tensile tubular steel |
| Front Suspension | Double wishbone/6.7 in |
| Rear Suspension | Double wishbone/7.5 in |
| Tyres | |
|---|---|
| Wheels / Rim | Alloy |
| Front Tyre | AT 25 x 8-12 |
| Rear Tyre | AT 25 x 10-12 |
| Dimensions | |
|---|---|
| Length | 2195 mm |
| Width | 1181 mm |
| Height | 1219 mm |
| Seat Height | 909 mm |
| Wheelbase | 1285 mm |
| Kerb Weight | 45 kg |
| Ground Clearance | 239 mm |
| Fuel Tank Capacity | 19 litres |
| Additional Details |
|---|
| Final Drive : Selectable 2WD/4WD with variable control front differential lock, shaft Turning Radius : 3200 mm |
