Front: 12G | Heavy Duty | Stainless | Black | 243 mm
Rear: 12G | Heavy Duty | Stainless | Black | 198 mm
Bottom Bracket
Neco B910
Axle Length: 164
BB Length: 100 mm
Taper: English Square
Motor Details
750 Watts / Bafang
5:1 Geared hub motor for higher torque output
290 RPM Super high speed winding
Low-drag freewheeling clutch
Shimano cassette standard
Display
LCD Matrix Display
Matrix Display with 120 x 64 Pixels
Customized interface with 3-buSon layout
7 Levels assist: 0, ECO, 1, 2, 3, SPORT (28 mph), RACE (Unlimited)
Basic and Advanced display modes
Water resistant IP65
Backlit illuminated display
5 Pin quick-connect cable with brass lock-ring
Push buSon start up
Electricals
Battery
52V / 19.2 Ah Hyper Extended Range Battery
52 Volts system (14S6P Configuration
995 Wh Capacity
LG Chem (Korea)
45 Amp high rate BMS
84 Cells / 18650 Type
Custom designed wide format inclosure
Lockable and removable from the bike
On-bike and off-bike charging capable
Charger
52V / 2 Amps Standard charger (included)
2 Amps max charge rate
3 Pin XLR Connector
UL Cer(fied
On-bike and off-bike charging
52V / 4 Amps Turbo charger (optional)
4 Amps max charge rate
3 Pin XLR Connector
UL Cer(fied
On-bike and off-bike charging
Controller
9 Transistor / 25 Amp Peak
Sine wave FOC
Customized tuning algorithm
Thermally managed
52V LED light output
Overboost function
Fully poSed resistant construction
Cruise control func(on
Walk func(on
XT60 connectors
Firmware upgradable
Head Lamp
LED
Tail Lamp
LED
Brakes
Front Brake
180 mm ektro HD-E350 Hydraulic Disc or Logan HD-E500
Rear Brake
180 mm Tektro HD-E350 Hydraulic Disc or Logan HD-E500
Chassis and Suspension
Frame
6061 Aluminum Heat Treated Frame
Rear Suspension
Hardtail Configura(on
Tyres
Wheels / Rim
Double walled aluminum alloy rim
36 Hole 19mm inner wheel width
12G / 13G brass grommets
High pressure rim strip
Flat Black
Front Tyre
Kenda Krusade K1188 or CST C-1752
26” x 4.0”
3 mm Puncture Protection
Rear Tyre
Kenda Krusade K1188 or CST C-1752
26” x 4.0”
3 mm Puncture Protection
Accessories
52V / 8 Amps Advanced fast charger (optional)
Grin Tech / Cycle Stator
8 Amp max charge rate
3 Pin XLR connector
UL Certified
80% Charge setting
Storage charge setting
Fully programmable
Water resistant
On-bike and off bike charging
Additional Details
Battery Details:
- 8 Amp charge capable
- 3-Pin XLR Charge Port
- Dual fuse setup
- IP 67 Illuminated power button
- 3C Discharge range
- 600 Charge cycles to 60%
Throttle Control
- Thumb Throttle (included)
- Right or left side mountable
- Throttle set to 20 mph per e-bike regulations)
Performance
- Default Configuration: Class 2 E-Bike 20mph (32 km/h)
- Class 3 Capable: 28 mph (45 km/h)
- Optional Configuration: Class 3 and Class 1 E-Bike
- Optional Configuration: Race Track Mode: 28 mph in Pedal Assist
Pedal Sensors
- Advanced Torque and Cadence Dual Sensor
- Torque sensor (included)
- Rear Drop-out frame-mounted strain gauge
- 1,000 samples per second
- Cadence sensor (included)
- 104 poles per crank revolu(on (maximum)
- Digitally filtered output
