Front: 12G | Heavy Duty | Stainless | Black | 243 mm
Rear: 12G | Heavy Duty | Stainless | Black | 198 mm
Chainrings
Pro Wheel 52T
Aluminum CNC | 170 mm
Outside and Inside chain guide
Bottom Bracket
Neco B910
Axle Length: 164
BB Length: 100 mm
Taper: English Square
Motor Details
750 Watts / Bafang
5:1 Geared hub motor for higher torque output
290 RPM Super high speed winding
Low-drag freewheeling clutch
Shimano cassette standard
Display
LCD Matrix Display
Matrix Display with 120 x 64 Pixels
Customized interface with 3-button layout
7 Levels assist: 0, ECO, 1, 2, 3, SPORT (28 mph), RACE (Unlimited)
Basic and Advanced display modes
Water resistant IP65
Backlit illuminated display
5 Pin quick-connect cable with brass lock-ring
Push button start up
Electricals
Battery
52V / 19.2 Ah Hyper Extended Range Battery
52 Volts system (14S6P Configuration)
995 Wh Capacity
LG Chem (Korea)
45 Amp high rate BMS
84 Cells / 18650 Type
Custom designed wide format inclosure
Lockable and removable from the bike
On-bike and off-bike charging capable
8 Amp charge
Charger
52V / 2 Amps Standard charger (included)
- 2 Amps max charge rate
- 3 Pin XLR Connector
- UL Certified
- On-bike and off-bike charging
- 52V / 4 Amps Turbo charger (optional)
- 4 Amps max charge rate
- 3 Pin XLR Connector
- UL Certified
- On-bike and off-bike charging
52V / 8 Amps Advanced fast charger (optional)
- Grin Tech / Cycle Satiator
- 8 Amp max charge rate
- 3 Pin XLR connector
- UL Certified
80% Charge setting
Storage charge setting
Fully programmable
Controller
9 Transistor / 25 Amp Peak
Sine wave FOC
Customized tuning algorithm
Thermally managed
52V LED light output
Overboost function
Fully potted resistant construction
Cruise control function
Walk function
XT60 connectors
Firmware upgradable
Head Lamp
Front LED Light (included)
1,050 Lum
CREE 7 Watt
10-60V input
Aluminum body design
Powered by main battery
Waterproof design IP69
Display controlled on/off function
Tail Lamp
Rear LED Light (included)
Star Union Rear LED Tailight
Blinking and steady mode
Includes reflector
Batteries included
