Neco B910
Axle Length: 164
BB Length: 100 mm
Taper: English Square
Motor Details
1,000 W RetroBlade Geared Hub Motor
5:1 Geared hub motor for higher torque output
425 RPM Super high speed winding
Custom designed RetroBlade cast aluminum wheels
Low-drag freewheeling clutch
Shimano cassette standard
Electricals
Battery
52V / 19.2 Ah Hyper Extended Range Battery
52 Volts system (14S6P Configuration)
995 Wh Capacity
LG Chem (Korea)
45 Amp high rate BMS
84 Cells / 18650 Type
Custom designed wide format inclosure
Lockable and removable from the bike
On-bike and off-bike charging capable
Charger
52V / 2 Amps Standard charger (included)
2 Amps max charge rate
3 Pin XLR Connector
UL Certified
On-bike and off-bike charging
52V / 4 Amps Turbo charger (optional)
4 Amps max charge rate
3 Pin XLR Connector
UL Certified
On-bike and off-bike charging
Controller
12 Transistor / 35 Amp Peak
Sine wave FOC
Customized tuning algorithm
Key switch ignition start
Thermally managed
52V LED light output
Overboost function
Fully potted resistant construction
Cruise control function
Walk function
XT60 connectors
DC-DC 12 V converter up to 10A
Head Lamp
Custom Designed 2,000 Lumen Headlamp w/ Halo DRL
4 Element projector high beam LED
Halo ring daytime running light
CREE 20 Watt LED
Powered by main battery
Waterproof design IP69
Display controlled on/off function Halo
Switch controller on/off high beam LED
Tail Lamp
Rear Combo LED Light with Brake Light and Turn Signals
Always on taillight
LED brake light function
Right and left turn signals
White LED license plate illuminator
Brakes
Front Brake
Tektro HD-E350 Hydraulic Disc
Rotors: Front: 180 mm | Rear: 160 mm
Hose: Front: 1,000 mm | Rear: 1,850 mm
Pad: Low-noise organic compound| E10.11 | B01S Style
Rear Brake
Tektro HD-E350 Hydraulic Disc
Rotors: Front: 180 mm | Rear: 160 mm
Hose: Front: 1,000 mm | Rear: 1,850 mm
Pad: Low-noise organic compound| E10.11 | B01S Style
Chassis and Suspension
Frame
6061 Aluminum Heat Treated Frame
Integrated & removable down-tube battery
Custom Designed Hidden cable channel system
CNC battery compartment
Water bottle cage mount
Rear pannier rack mount
Fender stay mounts
Rear Suspension
Steel Spring Suspension
Length: 310 mm
Tyres
Wheels / Rim
Custom designed cast aluminum wheel
Retro Blade front wheel
Flat Black
Front Tyre
Innova HV-5189 Custom with 5mm Layer
Size: 20” x 4.25”
Tread: Sheet Pattern
Circumference: 1770 mm
Protection: 5 mm puncture protection layer
Tube: 20 x 4.0 Schrader valve
Max Pressure: 35 psi
Recommended Pressure: 25 psi
Rear Tyre
Innova HV-5189 Custom with 5mm Layer
Size: 20” x 4.25”
Tread: Sheet Pattern
Circumference: 1770 mm
Protection: 5 mm puncture protection layer
Tube: 20 x 4.0 Schrader valve
Max Pressure: 35 psi
Recommended Pressure: 25 psi
Accessories
Fenders: Front and rear mud guards Included | Aluminum | Flat black
Mirrors Right and Left Mirrors (included)
Standard 8mm thread base
Horn
Integrated 52V Motorcycle Horn
Super Loud 100 dB
52 V Switch controlled
Rear Rack
Custom Designed Rack (included)
Powder Coated Aluminum
Pannier Rail
Light | Reflector holder
4 point frame mounted
50 lb (25 kg) rack payload
