Front: 13G Black | 232 mm | 275.5 mm
Rear: 13G Heavy duty | SAPIM | Stainless | Black | 232 mm
Chainrings
Pro Wheel 52T
Aluminum CNC | 170 mm
Outside chain guide
Inside chain catcher to eliminate chain drops
Bottom Bracket
VP-BC73
Axle Length: 126
BB Length: 68 mm
Taper: English Square
Motor Details
750 Watts / Bafang
1,300 Watts peak power @ 25A
80 Nm Peak torque
5:1 Geared hub motor for higher torque output
290 RPM Super high speed winding
Low-drag freewheeling clutch
Shimano cassette standard
Display
LCD Matrix Display
Matrix Display with 120 x 64 Pixels
Customized interface with 3-button layout
7 Levels assist: 0, ECO, 1, 2, 3, SPORT (28 mph), RACE (Unlimited)
Basic and Advanced display modes
Water resistant IP65
Backlit illuminated display
5 Pin quick-connect cable with brass lock-ring
Push button start up
Electricals
Battery
52V / 19.2 Ah Hyper Extended Range Battery
52 Volts system (14S6P Configuration)
995 Wh Capacity
LG Chem (Korea)
45 Amp high rate BMS
84 Cells / 18650 Type
Custom designed wide format inclosure
Lockable and removable from the bike
On-bike and off-bike charging capable
8 Amp charge
Charger
52V / 2 Amps Standard charger (included)
2 Amps max charge rate
3 Pin XLR Connector
UL Certified
On-bike and off-bike charging
52V / 4 Amps Turbo charger (optional)
4 Amps max charge rate
3 Pin XLR Connector
UL Certified
On-bike and off-bike charging
Controller
9 Transistor / 25 Amp Peak
Sine wave FOC
Customized tuning algorithm
Thermally managed
52V LED light output
Overboost function
Fully potted resistant construction
Cruise control function
Walk function
XT60 connectors
Firmware upgradable
Head Lamp
Front LED Light (included)
1,050 Lum
CREE 7 Watt
10-60V input
Aluminum body design
Powered by main battery
Waterproof design IP69
Display controlled on/off function
Tail Lamp
Rear LED Light (included)
Star Union Rear LED Tailight
Blinking and steady mode
Includes reflector
Batteries included
Tektro HD-E350 Hydraulic Disc
Rotors: 180 mm
Hose:1,750 mm
Pad: Pad: Low-noise organic compound| E10.11 | B01S Style
Chassis and Suspension
Frame
Sizes: Seat Tube Measurement
M: 16.5” (41.9 cm)
L: 18.0” (45.7 cm)
XL: 20.0” (50.8 cm)
6061 Aluminum Heat Treated Frame
Integrated & removable down-tube battery
Custom Designed Hidden cable channel system
CNC battery compartment
Integrated motor controller heat sink
Hydroformed top tube
Dual water bottle cage mount
Rear pannier rack mount
Fender stay mounts
Dual kickstand mounts
Rear Suspension
Hardtail Configuration
Tyres
Wheels / Rim
Double walled aluminum alloy rim
36 Hole 19mm inner wheel width
12G / 13G brass grommets
High pressure rim strip
Flat Black
Front Tyre
Schwalbe Marathon Plus
700C x 45C (45-622) | 28” x 1.75”
Achieves the highest level of puncture protection available
E-Bike Ready (ECE-R75) : Approved and tested for E-bikes up to 50 km/h
GreenGuard layer is 5 mm thick
"Anti-Aging" sidewall
Reflective sidewall strip for better visibility
40-70 PSI Recommended tire pressure
Bead: Wire (non-folding)
Tube: 700c x 45 | Schrader Valve
Rear Tyre
Schwalbe Marathon Plus
700C x 45C (45-622) | 28” x 1.75”
Achieves the highest level of puncture protection available
E-Bike Ready (ECE-R75) : Approved and tested for E-bikes up to 50 km/h
GreenGuard layer is 5 mm thick
"Anti-Aging" sidewall
Reflective sidewall strip for better visibility
40-70 PSI Recommended tire pressure
Bead: Wire (non-folding)
Tube: 700c x 45 | Schrader Valve
Additional Details
Throttle Control
Thumb Throttle (included)
Right or left side mountable
Throttle set to 20 mph per e-bike regulations
Pedal Sensors
Advanced Torque and Cadence Dual Sensor
Torque sensor (included)
Rear Drop-out frame-mounted strain gauge
1,000 samples per second
Cadence sensor (included)
104 poles per crank revolution (maximum)
Digitally filtered output
