Rear fork: single-arm cast aluminium fork with integrated drive unit
Front fork: twin-arm aluminium fork featuring parallel aluminium box-section arm to equalise braking torque
Charging Time
2 h 20 min
Display
High resolution 2.4″ colour screen
Electricals
Battery
Li-ion battery 8.3 kWh
Peak power output: 16kW
Charger
Charging capacity: 16A using 230 V wall socket and 3 kW onboard charger
optional: 16A using 400 V standardised socket and 8 kW onboard charger
Brakes
Front Brake
Dual-piston brake callipers front and rear, disc diameter 300 mm
Rear Brake
Dual-piston brake callipers front and rear, disc diameter 300 mm
Chassis and Suspension
Frame
Central aluminium frame, bolted
Tyres
Wheels / Rim
Front wheel: aluminium rim with 2 bolted flange discs
Rear wheel: aluminium rim with welded pressed flange
Dimensions
Length
2200mm
Height
1200mm
Seat Height
650 mm
Handlebar Width
814 mm
Wheelbase
1455 mm
Weight
159kg
Additional Details
Lean angle: 43°
Centre of gravity: 350 mm
Electric engine brake with power recuperation
Service life: in excess of 100,000 km and 80% residual capacity
