SRAM Code R 4-piston - Front Rotor 200mm 6-bolt 1.8mm
Rear Brake
SRAM Code R 4-piston - Rear Rotor 200mm 6-bolt 1.8mm
Chassis and Suspension
Frame
Full carbon fiber front and rear triangle utilizing an optimized carbon layup for the ENDURO category. Features fully guided Internal cable routing, carbon top link, titanium hardware, ISCG-05 tabs, threaded BB and updated molded frame protection and shuttle guard. Concentric bottom link with integrated flip chip to adjust GEO. Integrated CHAD Storage system with the ‘tube bag’ included. 170mm of rear wheel travel. Quick release rear axle (148mm boost hub spacing
Tyres
Wheels / Rim
Wheels : e Thirteen LG1 Enduro 30MM Alloy Rim / Intense alloy hub/boost
Rims : e Thirteen LG1 Enduro 30MM alloy rim 32h
Front Tyre
MAXXIS Minion DHF Maxx Terra 3C EXO+ 29" x 2.50"
Rear Tyre
MAXXIS Minion DHR II Maxx Terra 3C EXO+ 27.5" x 2.40"
Additional Details
Shock : FOX Performance elite DHX2 coil, rebound adjustments, 2 position climb switch, Shock size/Stroke: 205mm x 65mm upper mounting hardware Trunnion Lower Mounting Hardware: 8mm x 20mm.
Coil : 350 lbs (S Size for 54 - 64 kg rider weight) / 450 lbs (M Size for 64 - 73 kg rider weight) / 500 lbs (L Size for 73 - 80 kg rider weight) / 550 lbs (XL Size for 80 - 84 kgs rider weight)
