- Light crankshaft
- New combustion chamber Titanium connecting rods
- Dashboard TFT 5.5” color display
- Cruise control
- Bluetooth GPS MV Ride App for navigation mirroring, app
- Controlled engine, suspension and rider aids setup
- Launch Control FLC Front lift control Mobisat tracker
Four cylinder, 4 stroke, 16 valve,“D.O.H.C”, radial valve and DLC tappet
Engine Starting
Electric
Bore x Stroke
79mm x 50.9mm
Compression Ratio
13.4:1
Clutch
Wet, multi-disc with back torque limiting device and Brembo radial pump/lever assembly
Cooling System
Cooling with separated liquid and oil radiators
Maximum Power
208 PS @ 13000 RPM
Maximum Torque
116.5 NM @ 11000 RPM
Transmission
Cassette style; six speed, constant mesh
Drivetrain
Primary drive : 48/82
First gear: Speed : 14/37
Second gear: Speed : 16/33
Third gear: Speed : 18/31
Fourth gear: Speed : 20/30
Fifth gear: Speed : 22/29
Sixth gear: Speed : 21/25
Final drive ratio : 15/41
Top Speed
300kmph
Display
Dashboard TFT 5.5” color display
Electricals
Battery
Li-ion 12 V - 4.0 Ah
Brakes
Front Brake
320 mm Double floating disc with steel braking disc and aluminium flange - Brembo radial pump/level assembly
Front brake caliper : Brembo Stylema radial-type, single-piece with 4 pistons Ø 30 mm (Ø 1.18 in.)
Rear Brake
220 mm Single steel disc with Brembo PS13 brake pump
Rear brake caliper : Brembo with 2 pistons Ø 34 mm (Ø 1.34 in.)
ABS System
Continental MK100 with RLM (Rear Wheel Lift-up Mitigation) and with cornering function
Chassis and Suspension
Frame
CrMo Steel tubular trellis
Front Suspension
50 mm Marzocchi “UPSIDE - DOWN” telescopic hydraulic fork with adjustable rebound-compression damping and external spring preload.
Fork travel :
Rear Suspension
Progressive Sachs, single shock absorber with rebound and compression (High speed/Low speed) damping and spring preload adjustment
Tyres
Wheels / Rim
Front wheel: Material/size : Aluminium alloy 3,50” x 17”
Rear wheel: Material/size : Aluminium alloy 6,00” x 17”
Front Tyre
120/70 - ZR 17 M/C (58 W)
Rear Tyre
200/55 - ZR 17 M/C (78 W)
Dimensions
Length
2080mm
Width
805mm
Seat Height
845 mm
Wheelbase
1415 mm
Kerb Weight
186 kg
Ground Clearance
141 mm
Fuel Tank Capacity
16 litres
Additional Details
Engine management system : integrated ignition - injection system MVICS 2.1 (Motor & Vehicle Integrated Control System) with eight injectors (4 lower fuel injectors by Mikuni + 4 upper fuel injectors by Magneti Marelli with increased fuel flow). Engine control unit Eldor Nemo 2.1, throttle body bore 50 mm diameters full ride by wire Mikuni, pencil-coil with ion-sensing technology, control of detonation and misfire Torque control with four maps. Traction control with 8 levels + off and wheelie control with inertial platform.
Electronic quick-shift : MV EAS 3.0 (Electronically Assisted Shift Up & Down)
Rear swing arm pivot plates material : Aluminium alloy - Adjustable swingarm pivot height
Voltage : 12 V
Alternator : 350 W at 5.000 r.p.m
Single sided swing arm material : Aluminium alloy
Wheel travel : 120 mm (4.72 in.)
Fairing material : Thermoplastic
Steering damper : Öhlins EC with electronic manual and automatic adjustment modes
Trail : 97 mm (3.82 in.)
Environmental Standard : Euro 5
Combined fuel consumption : 6.8 l/100 km
CO2 Emissions : 158 g/km
