Book a Test Drive through Bikes4Sale and we will try to get you the best offer for Honda TRX520.
Red
| Vehicle Type | ATV |
| Fuel | Petrol |
| Engine Displacement | 518.00 cc |
| Engine Details | Liquid-cooled, 4-stroke |
| Engine Starting | Electric with auxiliary recoil |
| Bore x Stroke | 96mm x 71.5mm |
| Compression Ratio | 9.5:1 |
| Fuel System | Fuel Injection |
| Cooling System | Liquid-cooled |
| Transmission | 5-speed w/ reverse |
| Gear Shift Pattern | 1-N-2-3-4-5 |
| Brakes | |
|---|---|
| Front Brake | 2x 190mm Disc |
| Rear Brake | Drum |
| Chassis and Suspension | |
|---|---|
| Front Suspension | Independent Double Wishbone |
| Rear Suspension | Independent Double Wishbone |
| Tyres | |
|---|---|
| Wheels / Rim | Alloy |
| Front Tyre | 25x8-12 |
| Rear Tyre | 25x10-12 |
| Dimensions | |
|---|---|
| Length | 2106 mm |
| Width | 1205 mm |
| Height | 2213 mm |
| Seat Height | 877 mm |
| Wheelbase | 1269 mm |
| Weight | 250 kg |
| Kerb Weight | 297 kg |
| Ground Clearance | 190 mm |
| Fuel Tank Capacity | 14.7 litres |
