Programmed Fuel Injection (PGM-FI), 46mm downdraft throttle body
Cooling System
Liquid-cooled
Seating Capacity
1
Transmission
Close-ratio five-speed
Drivetrain
Final Drive #520 Chain; 13T/49T
Display
Digital
Brakes
Front Brake
Single 260mm disc with twin-piston caliper
Rear Brake
Single 240mm disc
Chassis and Suspension
Front Suspension
49mm inverted Showa fork with titanium oxide-coated lower legs; 13-position rebound and 15-position compression-damping adjustability; 12.2-inch travel
Rear Suspension
Pro-Link Showa single shock with adjustable spring preload, 11-position rebound and six-position high- and low-speed compression-damping adjustability; 12.4-inch travel
Tyres
Wheels / Rim
Spoke
Front Tyre
Dunlop MX33 80/100-21
Rear Tyre
Dunlop MX33 120/80-19
Dimensions
Seat Height
965 mm
Wheelbase
1481 mm
Kerb Weight
111 kg
Ground Clearance
335 mm
Fuel Tank Capacity
8 litres
Additional Details
- Valve Train: Unicam SOHC; four valves per cylinder
- Rake (Caster Angle); 27.1°
- Trail: 4.5 inches
