53T, 170 mm forged alloy, dual-sided aluminum guard
Pedals
Integrated reflectors, CrMo axle, standard 9/16" x 20 TPI threading
Pedal Assist System - PAS
5 level pedal assist with cadence sensor
Chain
KMC Z7 CrMo steel
Shifters
Shimano SL-TX50-7R shifter
Saddle
Comfort foam ergonomic saddle, integrated steel seat post, fixed angle
Headset
Semi-integrated, 1-1/8" straight steerer tube
Derailleur : Rear
Shimano TY300 7-speed derailleur
Spoke
12-gauge stainless steel, black
Stand
Steel Dual leg, spring loaded
Motor Details
500W brushless hub motor
Range
30 - 50+ miles
Charging Time
Up to 10 hours
Display
LCD display that shows speedometer, battery charge level, pedal assist level, odometer, and light indicator
Electricals
Battery
48V 15Ah (687Wh) UL Recognized Lithium-Ion Samsung 50E 21700 Cells
Battery Life : 5 Levels
Charger
54.6V, 2A smart charger Operates on 100-240V AC outlets
Controller
48V 500W
Head Lamp
LED headlight
Tail Lamp
Integrated tail light with brake light
Brakes
Front Brake
Tektro 180 mm
Rear Brake
Tektro 180 mm
Brake Lever
Aluminum alloy levers with motor cutoff switch and integrated bell
Chassis and Suspension
Frame
6061 Aluminum
Tyres
Wheels / Rim
Steel rims (26" front, 20" rear)
Front Tyre
26" x 3.0" puncture resistant liner
Rear Tyre
20" x 3.0" puncture resistant liner
Dimensions
Length
2128mm
Height
482mm
Seat Height
901 mm
Wheelbase
1419 mm
Weight
33kg
Accessories
Handlebar Water Bottle Holder
Front storage basket
Kid cargo carrier
Thule Yepp Maxi Seat
Flight Speed Extended Range Battery
Cell Phone Mount
Rear Storage Basket - Large & Small
