L-Twin, Desmodromic distribution, 2 valves per cylinder, air cooled
Bore x Stroke
98mm x 71mm
Compression Ratio
11:1
Clutch
Light action, wet, multiplate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run
Ignition
Electronic Fuel Injection, 55 mm Throttle Body with Full Ride by Wire (RbW)
Cooling System
Air Cooled
Maximum Power
86 HP @ 7500 RPM
Maximum Torque
88 NM @ 4750 RPM
Transmission
6 speed
Gear Shift Pattern
1-N-2-3-4-5-6
Seat
Dual Seat Motorcycle
Display
LCD Display
Electricals
Head Lamp
LED, Black metal "X" is recreated inside the Headlight
Tail Lamp
LED rear light with diffusion-light
Brakes
Front Brake
Dual 320 mm semi-floating discs, radially mounted Brembo Monobloc M4.32 callipers, 4-piston, axial pump with Bosch Cornering ABS as standard equipment
Rear Brake
245 mm disc, 1-piston floating calliper with Bosch Cornering ABS as standard equipment
ABS System
Cornering ABS
Chassis and Suspension
Frame
Tubular Steel Trellis Frame
Front Suspension
Marzocchi fully adjustable 45 mm usd fork
Rear Suspension
Kayaba monoshock, pre-load and rebound adjustable
Tyres
Wheels / Rim
Alloy
Front Tyre
3.50" x 18"
Rear Tyre
5.50" x 17"
Dimensions
Length
2190mm
Width
895mm
Height
1330mm
Seat Height
810 mm
Wheelbase
1514 mm
Weight
189kg
Kerb Weight
206 kg
Fuel Tank Capacity
15 litres
Additional Details
Rake : 24°.5
Trail : 111 mm
Standard : Euro 5
Total steering lock : 34°
CO2 emissions : 120 g/km
Front wheel : 10-spoke in light alloy, 3.50" x 18"
Rear wheel : 10-spoke in light alloy, 5.50" x 17"
Primary drive : Straight cut gears, Ratio 1.85:1
Final drive : Chain; Front sprocket 15; Rear sprocket 39
Ratio : 1=37/15 2=30/17 3=28/20 4=26/22 5=24/23 6=23/24
Exhaust : 2-1-2 system with catalytic converter and 2 lambda probes, twin stainless steel muffler with aluminium covers and end caps
