Slipper and self-servo wet multiplate clutch with hydraulic control
Fuel System
Bosch electronic fuel injection system, Ø 53 mm throttle bodies with Ride-by-Wire system
Cooling System
Liquid cooled
Maximum Power
113 HP @ 9000 RPM
Maximum Torque
94 NM @ 6750 RPM
Display
5" TFT colour display
Brakes
Front Brake
2 x 320 mm semi-floating discs, Radially mounted Brembo monobloc 4-piston 2-pad callipers, Radial Master Cylinder, Bosch Cornering ABS
Rear Brake
265 mm disc, 2-piston Brembo floating calliper, Bosch Cornering ABS
ABS System
Bosch Cornering ABS
Chassis and Suspension
Frame
Tubular steel trellis frame
Rear Suspension
Fully adjustable monoshock, Electronic compression, rebound damping and spring pre-load adjustment with Ducati Skyhook Suspension Evo (DSS), Aluminium double-sided swingarm
Tyres
Wheels / Rim
Front Wheel : Tubeless spoked wheel in light alloy 3.0" x 19"
Rear Wheel : Tubeless spoked wheel in light alloy 4.5" x 17"
Front Tyre
Pirelli Scorpion Trail II 120/70 ZR 19
(vehicle homologated also for Pirelli Scorpion Rally, same measures)
Rear Tyre
Pirelli Scorpion Trail II 170/60 ZR 17
(vehicle homologated also for Pirelli Scorpion Rally, same measures)
Dimensions
Weight
212kg
Additional Details
Exhaust System : Stainless steel single muffler, Catalytic converter and 2 lambda probes
Gearbox : 6 speed with Ducati Quick Shift up/down (DQS)
Primary Drive : Straight cut gears, ratio 1.84 : 1
Ratios : 1=37/15, 2=30/17, 3=28/20, 4=26/22, 5=24/23, 6=23/24
Final Drive : Chain, Front sprocket Z15, Rear sprocket Z43
Wheel Travel (Front/Rear) :170 mm / 170 mm (6.7 in / 6.7 in)
Consumption : 5,8 l/100 km
CO2 Emissions : 134 g/km
