Light action, Wet, Multiplate clutch with hydraulic control, Self-servo action on drive, Slipper action on over-run
Fuel System
Bosch electronic fuel injection system, eq 56 mm elliptical throttle bodies with Ride-by-Wire system
Cooling System
Liquid cooled
Maximum Power
158 HP @ 9500 RPM
Maximum Torque
128 NM @ 7500 RPM
Display
Colour TFT 5" display
Electricals
Head Lamp
LED
Tail Lamp
LED
Brakes
Front Brake
2 x 320 mm semi-floating discs, Radially mounted Brembo monobloc M4.32-piston callipers, 2-pad, radial pump, Bosch Cornering ABS
Chassis and Suspension
Frame
Tubular steel trellis frame
Front Suspension
48 mm fully adjustable usd fork, Electronic compression and rebound damping adjustment with Evo Ducati Skyhook Suspension (DSS)
Rear Suspension
Fully adjustable monoshock, Electronic compression, rebound damping and spring pre-load adjustment with Evo Ducati Skyhook Suspension (DSS), Aluminium double-sided swingarm
Tyres
Wheels / Rim
Front Wheel : Tubeless spoked wheel in light alloy 3" x 19"
Rear Wheel : Tubeless spoked wheel in light alloy 4.5" x 17"
Front Tyre
Pirelli Scorpion Trail II 120/70 ZR 19
(vehicle homologated also for Pirelli Scorpion Rally, same measures)
Rear Tyre
Pirelli Scorpion Trail II 170/60 ZR 17
(vehicle homologated also for Pirelli Scorpion Rally, same measures)
Dimensions
Seat Height
860 mm
Wheelbase
1592 mm
Weight
254kg
Kerb Weight
225 kg
Fuel Tank Capacity
30 litres
Additional Details
Exhaust System : Stainless steel single muffler, Catalytic converter and 2 lambda probes
Gearbox : 6 speed with up/down Ducati Quick Shift (DQS)
Primary Drive :Straight cut gears, ratio 1.84:1
Ratios : 1=38/14, 2=30/17, 3=27/20, 4=24/22, 5=23/24, 6=22/25
Final Drive : Chain; Front sprocket Z15, Rear sprocket Z43
Wheel Travel (Front/Rear) : 185 mm / 185 mm (7.3 in / 7.3 in)
CO2 Emission : 130 g/Km
Consumption : 5.5 l /100 Km
Standard : Euro 4
