Card dual opposed piston , 100 mm Master , Composite brake lines 200 mm Rotor
Rear Brake
Card dual opposed piston , 100 mm Master , Composite brake lines 200 mm Rotor
Chassis and Suspension
Front Suspension
Inverted non adjustable
Travel : 120 mm
Rear Suspension
Piggyback / Air Bladder
Travel : 100 mm
Tyres
Wheels / Rim
Front wheel : 1.85 x 17
Rear wheel : 2.15 x 17
Front Tyre
Michelin Pilot Street 80/90-17
Rear Tyre
Michelin Pilot Street 100/80-17
Dimensions
Seat Height
762 mm
Wheelbase
1223 mm
Kerb Weight
68 kg
Additional Details
Eco mode : 80 miles
Controller : High efficiency and power dense , 300 Amp , 3-phase AC controller and with regenerative deceleration
Power Pack : Angry Pixy Power X2
Capacity : 2.2 KWh
Charger Output : 7 A standard / 12 A optional
Final Drive : 5.3 to 01
Rake : 25 degree
Trail : 109 mm
Carrying capacity : 170 kg
