Dashboard & Controller
Configured for 3 riding modes:
- Explore: The ultimate mode during exploration. Limited speed to 45 km/h and 3-4h+ battery range
- Excite: Enduro or active trail riding. 1-2 h riding time
- Excel: Track and race mode, maximal torque and speed, riding time up to 1h
42 Nm peak torque on shaft / 280Nm on wheel 3000 rpm
Top Speed
80kmph
Stem
Aerospace grade 7075 aluminium stem with integrated dashboard
Handlebar
Aerospace grade 7050 aluminium, 800 mm wide, 20 mm rise, 31.8 mm
Chain
420 O-ring
Headset
FSA Stainless steel
Sprocket
Front sprocket : 12 teeth
Rear sprocket : 80 teeth
Motor Details
11 kW motor
Charging Time
0-80% takes 1,5 h to charge in a standard outlet
0-100% takes 2,5 h to charge in a standard outlet
Electricals
Battery
18650 lithium cells
51.8 Volt
50 Ah
2.6 kWh
Brakes
Front Brake
Motorcycle standard, four pistons callipers, alloy levers and 220 mm/3.2 mm stainless steel rotors
Rear Brake
Motorcycle standard, four pistons callipers, alloy levers and 220 mm/3.2 mm stainless steel rotors
Chassis and Suspension
Frame
6061 aluminium, extruded, forged and CNC jointed and welded
Body Carbon fibre reinforced PC
Swing arm 6061 aluminium extruded tube profile with linkage
Front Suspension
The upside down fork is air/oil sprung and features 38 mm stanchion tubes for extra rigidity and strength, with 204 mm travel, specially developed by Öhlins. Adjustable for high-speed compression, low-speed compression and low-speed rebound. The forks are equipped with Öhlins advanced 3 stage air springs with individual setup for ride heights and bottoming resistance.
Rear Suspension
205 mm. Öhlins TTX22 with CAKE internals and specific spring. Designed with linkage for best performance
Tyres
Wheels / Rim
Enlarged 25 mm stainless steel axles
Aerospace grade 7075 Power hubs
24 inch/50 mm 6061 alloy, triple chamber rims.
24 inch specially developed tires for durability and minimum trail wear
Dimensions
Seat Height
910 mm
Wheelbase
1310 mm
Kerb Weight
52 kg
Ground Clearance
300 mm
Additional Details
Weight : Dry 52 kg + battery 17 kg
Head angle / Fork angle : 65 degrees
Fenders : All fenders and side plates are made of PC/ABS
All bearings throughout the bike are SKF´s
