3 riding modes:
- Explore: The ultimate mode during exploration. Limited speed to 45 km/h and 3-4h+ battery range
- Excite: Enduro or active trail riding. 1-2 h riding time
- Excel: Track and race mode, maximal torque and speed, riding time up to 1h
3 brake modes:
- Free wheel
- 2-stroke like
- 4-stroke like, maximum regeneration of electricity to battery
Aerospace grade 7050 aluminium, 800 mm wide, 20 mm rise, 31.8 mm
Chain
420 O-ring
Headset
SKF Stainless steel conical bearings
Sprocket
Front sprocket: 12 teeth, rubber infused
Rear sprocket: 72 teeth
Motor Details
10 kW motor
Range
Mixed city riding (WMTC-II): 86 km / 53 miles
High speed riding (@70 km/h / 44 mph): 35 km / 22 miles
Charging Time
0-100% takes 2,5 h to charge in a standard outlet
Display
Speedometer, trip meter and odometer Battery status and power usage
Electricals
Battery
18650 lithium ion cells 51.8 Volt 50 Ah 2.6 kWh
Head Lamp
LED
Tail Lamp
LED
Brakes
Front Brake
Motorcycle standard, four pistons calipers and 220 mm/3.2 mm stainless steel discs Hand lever
Chassis and Suspension
Frame
6061 aluminium, extruded, forged, machined and painted
Front Suspension
The upside down fork is air/oil sprung and features 38mm stanchion tubes for extra rigidity and strength, with 204 mm travel, specially developed by Öhlins. Adjustable for high-speed compression, low-speed compression and low-speed rebound. The forks are equipped with Öhlins advanced 3 stage air springs with individual setup for ride heights and bottoming resistance.
Rear Suspension
205 mm. Öhlins TTX22 with CAKE internals and specific spring. Designed with linkage for best performance.
Tyres
Wheels / Rim
Enlarged 25 mm front axle Aluminium 6061 forged and CNC machined hubs 19×1.85” 7116-T6 aluminium motorcycle rims 19×3.00” dual sport motorcycle tires
Dimensions
Seat Height
910 mm
Wheelbase
1310 mm
Kerb Weight
62 kg
Ground Clearance
300 mm
Additional Details
Weight : Dry 62 kg + battery 17 kg
Head angle / Fork angle : 65 degrees
Fenders and bodywork : All fenders and bodywork are made of painted polycarbonate
L3e-A1E License requirement: A1
