| Vehicle Type | Bicycle |
| Stem | Syncros AM 1.5 Syncros Cable Integration System 4 degree rise / 7050 Alloy / 31.8mm / 1 1/8" |
| Handlebar | Syncros Hixon 1.5 Alloy 7050 Size S & M 15mm rise / Size L & XL 25mm rise Back sweep 8 Degree / 780mm Syncros Pro lock-on grips |
| Fork | Ohlins RXF36 m.2 Air TTX-Technology HSC - LSC - LSR adjustable / 15x110mm Axle 44mm offset / tapered steerer 150mm travel |
| Seat | Syncros Tofino 1.5 Regular Titanium rails |
| Seatpost | Syncros Duncan Dropper Post 1.5 34.9mm Size S 150mm / Size M 170mm / Size L & XL 200mm |
| Crankset | Race Face Next R Carbon crankarm 143 Spindle / 55mm CL / DM32T SHI |
| Chain | Shimano XT CN-M8100 |
| Shifters | Shimano XT SL-M8100-IR / Rapidfire Plus Ispec EV clamp |
| Headset | Syncros - Acros Angle adjust & Cable Routing HS System +-0.6 degree head angle adjustment ZS56/28.6 – ZS56/40 MTB |
| Derailleur : Rear | Shimano XT RD-M8100 SGS Shadow Plus / 12 Speed |
| Cassette | Shimano XT CS-M8100-12 / 10-51 T |
| Bottom Bracket | Race Face BB92 Dia 30mm / Double Row / Ext. Seal |
| Brakes | |
|---|---|
| Front Brake | Shimano XT M8120 4 Piston Disc, Shimano SM-RT76 / 6 Bolt / 203mm Rotor |
| Rear Brake | Shimano XT M8120 4 Piston Disc, Shimano SM-RT76 / 6 Bolt / 180mm Rotor |
| Chassis and Suspension | |
|---|---|
| Frame | Bold Linkin 150 / Carbon HMX Integrated Suspension Technology / IST VP Vario Tech, Head angle and BB height / Syncros Cable Integration System BB92 / UDH Interface / 12x148mm with 55mm Chainline |
| Rear Suspension | FOX NUDE 5T EVOL Trunnion Custom w. travel / geo adj. 3 modes: Lockout-Traction Control-Descend Custom large Air volume / DPS / Reb. Adj. Travel 150-100-Lockout / T185X55mm |
| Tyres | |
|---|---|
| Wheels / Rim | Syncros Revelstoke 1.5 6 Bolt F: 15x110mm, R: 12x148mm 30mm Tubeless ready rim 28H / XD Driver Syncros Axle w/Removable Lever with Tool |
| Front Tyre | Maxxis Minion DHF / 2.5" / 60TPI Foldable Tubeless Ready / EXO |
| Rear Tyre | Maxxis Minion DHF / 2.5" / 60TPI Foldable Tubeless Ready / EXO |
| Dimensions | |
|---|---|
| Weight | 13.9-14.3 kg |
