Single disc brake, diameter 10.9" (276 mm), double-piston floating caliper
ABS System
BMW Motorrad Integral ABS Pro (part-integral, slant-layer-optimized)
Chassis and Suspension
Frame
Two-section frame, front- and bolted on rear frame, load-bearing engine
Front Suspension
BMW Motorrad Telelever; stanchion diameter 1.5" (37 mm), central spring strut
Rear Suspension
Cast aluminium single-sided swing arm with BMW Motorrad Paralever; WAD strut (travel-related damping), spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable at handwheel
Tyres
Wheels / Rim
Cross spoke wheels
Front Tyre
3.00 x 19"
120/70 R 19
Rear Tyre
4.50 x 17"
170/60 R 17
Dimensions
Length
2270mm
Width
980mm
Height
1460mm
Seat Height
890 mm
Wheelbase
1504 mm
Kerb Weight
268 kg
Fuel Tank Capacity
36 litres
Reserve Tank Capacity
5 litres
Additional Details
Emission control: Closed-loop 3-way catalytic converter
Fuel type: Unleaded super, octane number 95 (RON), adaptive fuel quality regulation (91 to 98 RON)
Alternator: Three-phase alternator with 510 Watt nominal power
Caster: 3.8" (95.4 mm)
Steering head angle: 65.1°
Inner leg curve: 76.8" / 78.3" (1,950 mm / 1,990 mm)
